Cheap Yellow Monster

v2.14.00

WiFi 6 & BLE security toolkit with SigInt & Wardriving — now running on three boards

🎬 Featured Videos

CYM in the wild — Anubis ▶ · CYM Firmware Review (v2.12.0) — Valleytech Custom Solutions ▶ · CYM Installation Tutorial — Yellow Purple ▶

Cheap Yellow Monster — CYM-NM28C5

Cheap Yellow Monster is a portable, touchscreen-driven wireless security, BLE, GPS wardriving, and RF experimentation toolkit. It runs on three boards from a single shared firmware source tree — see Supported Hardware below.

The NM-CYD-C5 / MonsterC5-style ESP32-C5-WIFI6-KIT hardware family remains the primary, preferred platform: it's the board CYM was originally built for, it's where new features land first, and — paired with the optional NM-RF-HAT expansion board — it has by far the widest RF hardware support (Sub-GHz, nRF24, NFC/RFID, IR, and more).

CYM brings together many of the workflows people normally jump between separate ESP32 firmwares to get: WiFi scanning, WiFi analysis, deauth monitoring, Evil Portal-style testing, handshake capture, BLE scanning, BLE capture workflows, GPS wardriving, RF expansion support, and touchscreen-driven field use. It is designed to be a compact handheld platform for wireless research, education, defensive testing, and hardware hacking.

Where CYM really separates itself is in the field workflow. It includes GPS-aware wardriving with stability handling for GPS loss, including last-known-position behavior so brief GPS dropouts do not destroy a capture session. It also includes BLE capture-list management so you can compare sessions, identify devices that are unique to a location, and find devices that are common across multiple captures.

CYM also includes a GATT Walker for deeper BLE analysis. Instead of only listing nearby BLE devices, the GATT Walker performs extended discovery of BLE GATT services, characteristics, descriptors, and exposed features, then logs the results to SD card in structured JSON. This makes the data useful for deeper offline analytics, fingerprinting, comparison between devices, and long-term BLE research.

Built entirely on ESP-IDF 6.0 with LVGL 8.x for the UI, CYM leverages the ESP32-C5's RISC-V core, WiFi 6 support, BLE capabilities, and modern embedded architecture. The interface uses a Material-style dark UI designed for practical handheld use on the 2.8" resistive touch display.

CYM also supports the NM-RF-HAT ecosystem, including NFC/RFID, CC1101 Sub-GHz experiments, nRF24, RF433, and infrared features where supported by the hardware. CC1101 workflows include frequency correction support, allowing PPM adjustment based on observed frequency shift to help compensate for module crystal tolerance and improve Sub-GHz accuracy in the field.

The project was originally inspired by Pancake, but has diverged substantially in target hardware, build system, UI framework, feature set, and architecture. CYM targets the ESP32-C5 / NM-CYD-C5 hardware family, uses ESP-IDF instead of Arduino, uses LVGL 8 for the UI, and has grown into a standalone firmware platform rather than a fork.

CYM also comes from the broader MonsterC5 / JanOS ecosystem. It was branched with Janek / JanOS, and the Cheap Yellow Monster name was approved by OyczE, the designer of the MonsterC5. I beta test for the LAB5 Team and have great respect for everyone involved. CYM is my contribution back to that community.

The NM-CYD-C5 can be purchased at nmminer.com. Additional purchase sources and full hardware documentation are available on the official board repository.

Supported Hardware

CYM builds and flashes for three boards from one shared firmware source tree.

Board	Status	What you get
NM-CYD-C5 — optionally with the NM-RF-HAT	⭐ Primary / preferred hardware for all features	The full feature set: WiFi 6 (2.4 + 5 GHz), BLE 5, 802.15.4 (Zigbee/Thread/WirelessHART passive survey), ESP-NOW, GPS wardriving — and, with the NM-RF-HAT, CC1101 Sub-GHz, nRF24, PN532 NFC/RFID, and IR. New features land here first.
Classic CYD (ESP32-2432S028R)	✅ Supported	WiFi (2.4 GHz — original single-core ESP32, no WiFi 6 / 5 GHz radio), BLE, ESP-NOW, GPS wardriving. No 802.15.4 (the chip has no 802.15.4 radio). NM-RF-HAT reachable via an SD Card Shim adapter.
Waveshare ESP32-C5-Touch-LCD-2.8 (WS-C5-28)	✅ Supported — new	On par with the NM-CYD-C5's core feature set — WiFi 6, BLE 5, 802.15.4, ESP-NOW, GPS wardriving — plus onboard hardware NM-CYD-C5 doesn't have: 6-axis IMU, temperature/humidity sensor, RTC, and an I2S audio codec. Many new features planned to take advantage of that extra hardware.

All three flash from the same web-based flasher (board selector at the top) and build from the same main.c.

Features Overview

Category	Features
WiFi Scanning	Active scan, per-channel analysis, RSSI, client enumeration; networks color-coded by MFP status (green = MFP Required, yellow = MFP Capable, red = MFP not supported)
WiFi Attacks	Deauth, Evil Twin, Captive Portal, Blackout, Snifferdog, SAE Overflow
Handshake Capture	WPA/WPA2 4-way handshake capture (PCAP & HCCAPX)
Karma AP	Respond to probe requests, rogue access point
Chanalizer	Wide 520 px WiFi channel map — auto-scrolling left/right with touch-drag pause; SSID color grouping, group legend, channel annotations; portrait 240 px viewport over 2.4 GHz + 5 GHz
WiFi Band Scope	Promiscuous RSSI per-channel waterfall (2.4 GHz 13-ch or 5 GHz 25-ch); band toggle updates axis label and resets peaks; 60 ms dwell / 0.8 s full 2.4 sweep
Drone Detector	Dual-mode (BLE5 extended + WiFi 2.4/5 GHz) passive Remote ID scanner. Passively monitors for ASTM F3411-compliant drone Remote ID beacons via BLE service UUID 0xFFFA and WiFi ODID management frames; DJI presence by OUI / service UUID 0xFFF0. Alternates BLE and WiFi scan phases; logs to SD. Note: DJI drones using OcuSync 4 broadcast Remote ID only on the ground.
Drone Spoof	Broadcasts a synthetic ASTM F3411 Remote ID beacon over BLE or WiFi. Configurable UAS ID, operator ID, GPS coordinates, altitude, speed, and heading. For RF research, drone regulation testing, and authorized counter-UAS research.
Wardriving	GPS + WiFi + BLE logging, dual-band (2.4 GHz / 5 GHz / Both); speed-adaptive capture (Stationary / Walking / Driving profiles, GPS-triggered with hysteresis); D-UCB channel bandit rewards new networks per dwell, DFS tier-weighted at speed; BLE-only mode fixed (v2.13.x — was collecting 0 devices); BLE dashboard B\|MAC\|Name\|RSSI with active scan + SCAN_RSP name backfill; CSV fsync — power-cut safe at 10/20/30 s verified; auto-rotation into journey-grouped parts (WD_Wifi_<stamp>-NNN.csv / WD_BLE_<stamp>-NNN.csv); WiGLE CSV 1.6, WiGLE + WDG Wars upload; GPS mark waypoints (GPX); last-known position hold with 150 m stale accuracy; AltitudeMeters + AccuracyMeters filled from real GPS fix
GPS	NMEA auto-syncs system clock; boot-time baud auto-detect (module keeps baud in battery-backed RAM across power cycles); optional 115200 / 5 Hz opt-in with verify-and-revert safety (5.2 fix/s measured under full wardrive load; 18 m → 3.6 m between fixes at 65 km/h); multi-vendor rate commands (CASIC, MTK, u-blox UBX); GPS status icon in the top bar of every screen; last-known position persisted to NVS; manual fallback editor in Settings → GPS Info
BLE	Tracker Scanner: AirTag, Samsung SmartTag, and Tile detection — four-category summary (AirTags / AirTag? Prox / SmartTags / Tiles); Found Tags list with type badge, Track, GATT Walk, and Ring buttons; Ring confirmed working on AirTag (Apple FMN non-owner `{0x01}` trigger); SmartTag and Tile require owner auth (greyed note). BLE Locator, GATT Walker fingerprinting, BT Observer multi-walk (with advanced advertising fingerprinting — AD-type decode, Company ID lookup, URIs, flags), Bluetooth Lookout, BLE Spam (8 modes incl. Sour Apple), Device Spoof (general + directed), BLE Disconnect (directed), BLE PCAP (Kismet PCAPNG; advertising-layer reconstruction from NimBLE reports; BLE 5.0 extended advertising support), BlueDuck (BLE HID DuckyScript keyboard injector), HoneyPair (BLE persona honeypot), WhisperPair (CVE-2025-36911 Google Fast Pair KBP bypass — auto-scan, sequential run-all FP targets, AES-128-ECB exploit); BT Scan & Select supports Save List (GPS-tagged JSON snapshot of every device found); Matter [M] detection passive tagging of Thread/BLE Matter devices by GATT service `0xFFF6`; GATT Interactive (live read/write/subscribe to individual characteristics after walk); GATT HID Decoder (parses HID Report Map, decodes live keyboard/mouse input); GATT Profile Snapshots (Saved Clones) browser; BLE Notify Logger (BLE MITM)
Deauth Client	Passive discovery of clients associated with any nearby AP — without connecting or running any attack. Lists client MACs, associated BSSID, RSSI, and last-seen time; useful for pre-attack recon and monitoring
Zigbee Scout	IEEE 802.15.4 passive wardrive using the ESP32-C5's built-in PHY; logs PAN IDs, channel, RSSI, device addresses, and NWK/APS frame metadata to WiGLE-compatible CSV + PCAP; RSSI locator locks onto a specific PAN; logs to `/sdcard/lab/zigbee/`
ESP-NOW Scout	Passive ESP-NOW device discovery and packet analysis. Hops channels 1–13 (200 ms/ch) sniffing vendor-specific 802.11 Action frames (OUI `18:FE:34`, type `0x04`). Tracks up to 32 unique senders with src/dst MAC, channel, RSSI, packet count, first/last seen timestamp, and broadcast vs. unicast (encrypted) status. Tap any discovered device to lock the radio to its channel and open a session sub-screen. Session modes: This Dev Pkt Log (filtered to selected src MAC) and All Ch Pkt Log (every ESP-NOW frame on that channel). Packet log shows last 20 frames in a terminal-style dark view — hex dump, timestamp, RSSI, and ASCII interpretation for broadcast (plaintext) frames. Encrypted unicast frames show an AES-128-ECB probe result if an LMK is loaded from `profiles.json`. Export full 200-frame ring buffer to timestamped `.txt` on SD. Known-device labels and LMK keys loaded from `/sdcard/lab/espnow/profiles.json`. Discovery device table exported to timestamped JSON. Logs to `/sdcard/lab/espnow/`.
BlueDuck	BLE HID keyboard injector — pairs as any of 9 device personas; executes DuckyScript payloads from SD card (preloaded into PSRAM at boot, immune to SD DMA OOM during BLE); HUMAN_MODE variable-speed typing; Android (Win+H/B/N), Windows (Win+R/L, Ctrl+Shift+Esc), and iOS (Cmd+H/Space) keyboard shortcut support; session JSONL log to SD card; 13-script library included
HoneyPair	Continuous BLE persona honeypot — cycles 9 consumer device personas every 5 min, logs all pairing attempts to JSONL; GATT/HID enumeration on any pairing device; persona MACs randomised and deduplicated
Deauth Monitor	Passive detection of nearby deauth attacks
Credentials	Captive portal credential capture, WPA-SEC upload
TX Power Mode	Selectable Normal / Max Power for WiFi and BLE — persisted across reboots
Data Transfer	Self-hosted AP file server (TheLab) and WiFi client file server — browse, upload, create directories, and recursively delete folders from any browser; client IP logged to serial; IP shown on screen
NM-RF-HAT	Hardware addon board for RF expansion -- IR capture/replay/LED RMT (24-btn NEC RGB LED strip controller)/Universal Remote/TV-B-Gone (Flipper .ir); RF433 OOK capture/replay/OOK Scan/Fox Hunt/Jammer (Flipper .sub); CC1101 Sub-GHz: Band Scope (SDR freq marker + Hunt), Fox Hunt (RSSI bug-hunter haptic, 300-928 MHz tunable), RAW Capture+Replay, Z-Wave Scout, TPMS 315+433 MHz, Alarm Sensor decoder (EV1527), Weather Station decoder (Fine Offset) (Flipper .sub); nRF24L01+ 2.4 GHz: Ch Scan/Sniffer/Jammer/Futaba S-FHSS/Fox Hunt (Flipper .nrf24); PN532 NFC/RFID: scan+Read All, NTAG213/215/216 full page dump, Clone/Write to blank NTAG, MIFARE Classic key-dict test, save/emulate/.nfc import+export (Flipper .nfc); DIP switch per module
Fox Hunt	Ham radio-style RF proximity tracker on all three sub-GHz radios. CC1101: tunable 300-928 MHz, RSSI bar + peak hold, adjustable squelch, bug-hunter haptic (pulse rate scales from 1 pulse/1.5 s at threshold to continuous at strong signal — always 100% motor strength for reliable feel). nRF24: carrier-detect rate bar across 2400-2525 MHz in 1 MHz steps. RF433: GPIO edge-count activity bar at 433.92 MHz. All three use the vibrator for proximity feedback. Band Scope → Fox Hunt tap-through with SDR-style draggable yellow frequency marker.
OOK Protocol Decoding	CC1101 Alarm Sensor: decodes EV1527 315/433 MHz OOK alarm sensors (door contacts, PIR, smoke, flood) — 24-bit address + 4-bit channel, RSSI, trigger count, scrollable live list. CC1101 Weather Station: decodes Fine Offset 433.92 MHz weather sensors (WH65/WH57/WS80/WH31 and similar) — temperature (°C), humidity, battery, RSSI, scrollable list. RF433 OOK Scan: same EV1527 decoder using the R4A_433 superheterodyne receiver for higher sensitivity at exactly 433.92 MHz.
SD Card Remount	Settings → SD Card → Remount SD Card: unmounts and re-mounts at 20/10/5 MHz fallback without physical eject — useful after a crash or RF-HAT FPC contact issue.
CC1101 Crystal Cal	CC1101 HW Test → Crystal Calibration. Consumer 26 MHz crystals drift ±8.7-17 kHz at 433 MHz (±20-40 ppm). Error is proportional — the same ppm causes 2× more Hz deviation at 915 MHz vs 433 MHz. CAL TX 433 button transmits a continuous carrier for measurement. Set Offset popup accepts ±130 kHz (= ±300 ppm). Stored as PPM so it scales correctly to all bands automatically. Persists to NVS ("cc1101_ppm" key).
UI	Material dark theme, touch gestures, screen dimming, screenshots — all screens portrait 240×320
Storage	SD card for handshakes, wardrive logs, GATT Walker JSON, screenshots, file tree browser

Menu Map

Complete navigation tree as of v2.13.43. Items marked [stub] are placeholders with "Coming in next version" screens. Items marked [RF-HAT] require the NM-RF-HAT expansion board enabled in Settings → Hardware Options.

Home
├── WiFi
│   ├── Scan & Attack
│   ├── WiFi Attacks
│   │   ├── Blackout (Evil Twin)
│   │   ├── Handshaker
│   │   └── Portal
│   ├── Deauth Monitor
│   ├── Deauth Client
│   ├── WiFi Observer (Sniffer / Karma)
│   ├── Drone Stuff
│   │   ├── Drone Detect
│   │   └── Drone Spoof
│   ├── Chanalizer
│   ├── WiFi Scope
│   └── ESP-NOW Scout
│       └── (tap device) → Session
│           ├── This Dev Pkt Log
│           └── All Ch Pkt Log
├── Bluetooth
│   ├── BT Scan & Select
│   ├── BT Observer
│   ├── AirTag Scan
│   ├── BT Locator
│   ├── BT Lookout
│   ├── BT Attacks
│   │   ├── BLE Spam
│   │   ├── Device Spoof
│   │   ├── Blue Duck (BLE HID DuckyScript)
│   │   ├── Whisper Pair (CVE-2025-36911)
│   │   └── BLE Notify Logger (BLE MITM)
│   ├── BLE PCAP
│   ├── Honey Pair
│   ├── List Wizard
│   └── GATT Profile Snapshots ← browse GATT profiles captured by GATT Walker (UI label: Saved Clones)
├── Wardrive
│   ├── Start Wardrive
│   ├── Options
│   └── Manage Data
├── Settings
│   ├── Compromised Data
│   │   ├── Evil Twin Passwords
│   │   ├── Portal Data
│   │   └── Handshakes
│   ├── Timing
│   ├── Download Mode
│   ├── Screen
│   │   └── Recalibrate Touch
│   ├── SD Card
│   │   ├── Validate & Provision
│   │   ├── Free Space
│   │   ├── File Tree
│   │   ├── New Folder
│   │   ├── Delete File
│   │   ├── Remount SD Card
│   │   └── Format SD Card
│   ├── GPS Info
│   ├── Hardware Options
│   │   └── NM-RF-HAT Enable / Disable
│   ├── Data Transfer
│   │   ├── AP File Server
│   │   ├── WiFi Client
│   │   └── Wardrive Upload [stub]
│   └── Vibrator Test
├── Go Dark (display off)
├── Zigbee Scout
├── Infrared [RF-HAT DIP 4]
│   ├── Capture       (keyboard naming: remote name → signal name → save)
│   ├── Replay  →  <Remote>.ir  →  Signal list
│   ├── LED RMT       (28-button NEC RGB LED strip remote; library selector: Custom/44-Key)
│   ├── Edit Files    (rename or delete remotes and individual signals; teal-cursor keyboard)
│   ├── Universal Remote
│   ├── TV-B-Gone
│   └── IR Jammer
├── Radio [RF-HAT]
│   ├── CC1101 Sub-GHz [DIP 1]  — 2 pages
│   │   ├── Page 1
│   │   │   ├── HW Test  (crystal calibration offset + CAL TX 433 carrier)
│   │   │   ├── Band Scope (SDR freq marker + Hunt button)
│   │   │   ├── Fox Hunt (300-928 MHz tunable, RSSI+squelch, haptic)
│   │   │   ├── Capture RAW
│   │   │   ├── Replay RAW
│   │   │   ├── Saved Files
│   │   │   ├── Z-Wave Scout
│   │   │   ├── TPMS Monitor (315 / 433 MHz, 20 sensors)
│   │   │   └── Weather Station (Fine Offset decoder — temp/humidity/battery)
│   │   └── Page 2
│   │       ├── POCSAG Pager [stub]
│   │       ├── Alarm Sensor (EV1527 decoder — 315/433 MHz, 24-bit addr)
│   │       ├── RF Wardrive [stub]
│   │       ├── Decode Proto [stub]
│   │       ├── Jammer  (band: 315/433W/433N/868/915; 2-FSK ±381 kHz; 12-step sweep)
│   │       └── Brute Force [stub]
│   ├── nRF24L01+ 2.4 GHz [DIP 2]  — 2 pages
│   │   ├── Page 1
│   │   │   ├── HW Test
│   │   │   ├── Ch Scan (2400-2525 MHz, carrier detect)
│   │   │   ├── Sniffer
│   │   │   ├── Saved Files
│   │   │   ├── Jammer
│   │   │   ├── Futaba S-FHSS
│   │   │   └── Fox Hunt (channel tunable, haptic)
│   │   └── Page 2
│   │       ├── MouseJack [stub]
│   │       ├── Kb Inject [stub]
│   │       ├── Drone Scan [stub]
│   │       └── Game Pad [stub]
│   └── RF433 OOK/ASK [DIP 5]
│       ├── Capture
│       ├── Replay
│       ├── Jammer  (1 kHz OOK modulation, T2-433M transmitter)
│       ├── LBK Test (loopback)
│       ├── Fox Hunt (433.92 MHz fixed, edge-count activity, haptic)
│       └── OOK Scan (EV1527 decoder via R4A_433 superheterodyne RX)
└── NFC / RFID Hub  [always visible]
    ├── Chameleon Ultra  [BLE]
    │   ├── Scan & Connect
    │   ├── Read LF         ← EM410X / HID H10301 → .rfid
    │   ├── Read HF         ← ISO 14443-A → .nfc; Dump Card after detect
    │   ├── Slot Manager    ← browse / activate all 8 slots
    │   ├── Clone to Slot   ← write captured UID to any slot
    │   └── Load from SD    ← long-press .rfid/.nfc to load into active slot
    └── PN532 NFC  [RF-HAT DIP 3 — or standalone on CN1]
        ├── Scan & Read  →  Read All (full page dump)  →  Save / Export .nfc
        ├── Clone/Write  →  Select source  →  Clone to blank NTAG
        ├── Card Emulate →  Select saved card  →  Emulate / Stop
        ├── Key Test     →  MIFARE Classic dict attack
        ├── Saved Cards  →  load / emulate / Flipper .nfc import
        └── HW Test      →  PN532 I2C probe, I2C bus scan

Screenshots

Main Menu · WiFi Menu · Scan & Attack · Select Target · Wardrive

Hardware

This section (and the Pinout section below) documents the NM-CYD-C5 — the primary/preferred board, see Supported Hardware. For Classic CYD and Waveshare WS-C5-28 pin maps, see the wiki.

Component	Model	Interface
MCU	ESP32-C5-WROOM-1-N168R (RISC-V 240 MHz, 16 MB flash, 8 MB PSRAM)	—
Board	NM-CYD-C5 (RockBase-iot NerdMiner CYD)	—
Display	2.8" ST7789 TFT (240×320 portrait, 16-bit RGB565)	SPI @ 40 MHz
Touch	XPT2046 Resistive Touch (polling, T_IRQ not connected)	SPI @ 2 MHz
SD Card	MicroSD FAT32, max 32 GB (shared SPI2 bus with display and touch)	SPI @ 20 MHz
GPS	ATGM336H GPS+BDS Dual-Mode Module (Teyleten Robot, ASIN B09LQDG1HY; search "ATGM336H UART" if unavailable) — outputs NMEA 0183 GGA + RMC at 9600 baud, 3.3 V, onboard ceramic patch antenna	UART1 @ 9600 baud
LED	WS2812 NeoPixel (single, GPIO 27)	RMT / GPIO
Vibrator	ERM vibrator motor via SC8002B class-D amp (SPEAK header, GPIO 26) — optional add-on; requires 1N5819 + 1N4148 diode circuit; see Vibrator Motor Circuit section	LEDC PWM

Board reference: https://github.com/RockBase-iot/NM-CYD-C5

Pinout

Wiring Diagram

                       ESP32-C5 NM-CYD-C5
                      ┌──────────────────┐
                      │                  │
    Display ──────────┤ GPIO 7   (MOSI)  │──────── Touch / SD Card
    (shared SPI2)     │ GPIO 2   (MISO)  │         (shared SPI2)
                      │ GPIO 6   (SCK)   │⚠️
                      │                  │
    LCD CS ───────────┤ GPIO 23          │
    LCD DC ───────────┤ GPIO 24          │
    LCD BL ───────────┤ GPIO 25          │⚠️ strapping, safe after boot
                      │                  │
    Touch CS ─────────┤ GPIO 1           │
                      │                  │
    SD CS ────────────┤ GPIO 10          │
                      │                  │
    GPS TX (ESP→GPS) ─┤ GPIO 5           │
    GPS RX (GPS→ESP) ─┤ GPIO 4           │
                      │                  │
    NeoPixel ─────────┤ GPIO 27          │
                      │                  │
    SPEAK_IN (SC8002B)┤ GPIO 26          │ (vibrator motor driver)
                      │                  │
    Console ──────────┤ USB (JTAG/CDC)   │
                      └──────────────────┘

    ⚠️ = Strapping pins — safe after boot completes
    GPIO 16–22 (excl. 21) = Flash/PSRAM — never use

Complete GPIO Table

GPIO	Function	Interface	Notes
1	XPT2046 Touch CS	SPI	Active LOW
2	SPI MISO	SPI2	Shared: display + touch + SD
4	GPS RX (GPS→ESP)	UART	LP-UART
5	GPS TX (ESP→GPS)	UART	LP-UART
6	SPI SCK	SPI2	⚠️ Strapping pin; also ADC1_CH5 — do not configure as ADC (breaks SPI clock)
7	SPI MOSI	SPI2	⚠️ Strapping pin, safe after boot
10	SD Card CS	SPI	Active LOW
16–22 (excl. 21)	Flash/PSRAM	—	Never use
23	ST7789 Display CS	SPI	Active LOW
24	ST7789 DC (Data/Cmd)	Output
25	Backlight	Output	⚠️ Strapping, HIGH=on
26	SPEAK_IN → SC8002B amp	LEDC PWM	Vibrator motor driver; 333 Hz / 50% duty max; see Vibrator Motor Circuit
27	NeoPixel Data	RMT/GPIO	WS2812 LED

GPIO 6 / ADC1_CH5 conflict: The battery voltage ADC (BATTERY_ADC_CHANNEL ADC_CHANNEL_5) maps to GPIO 6, which is also SPI SCK. Calling adc_oneshot_config_channel on this pin silently reconfigures it away from SPI, killing SPI clock for display and touch. The battery ADC is permanently disabled in firmware for this board revision (if (false && init_battery_adc()...)).

XPT2046 Z1 pressure: Touch detection uses Z1 pressure threshold (> 400 raw counts). Z1 reads near 0 when untouched and rises above threshold when pressed — providing reliable touch detection even though explicit Z electrode PCB traces are not exposed.

SPI Bus Architecture

SPI2_HOST
├── ST7789 Display  (CS = GPIO 23, 40 MHz)
│   ├── MOSI = GPIO 7
│   ├── MISO = GPIO 2
│   ├── SCK  = GPIO 6
│   └── DC = GPIO 24
│
├── XPT2046 Touch   (CS = GPIO 1, 2 MHz)
│
└── SD Card         (CS = GPIO 10, 20 MHz)

Mutual exclusion via sd_spi_mutex

GPS Wiring — ATGM336H

Recommended module: Teyleten Robot ATGM336H GPS+BDS Dual-Mode Module (Amazon ASIN B09LQDG1HY, typically sold as a 2-pack)

If the link above is unavailable, search Amazon or AliExpress for: "ATGM336H GPS BDS module UART" or "Teyleten Robot ATGM336H". The module is also sold under other brand names (e.g. HiLetgo, KeeYees) — any ATGM336H-based board with a 4-pin header (VCC / GND / TX / RX) and a 3.3 V UART interface will work.

The ATGM336H is a compact GPS/BeiDou dual-mode GNSS module that outputs standard NMEA 0183 sentences (GGA, RMC) at 9600 baud over a 3.3 V UART interface. It is manufactured by ZHONGKEWEI (ATGM) and is a cost-effective drop-in replacement for the popular u-blox NEO-6M and NEO-M8N modules. The Teyleten Robot variant ships with an onboard passive ceramic patch antenna and a 5-pin 2.54 mm header (VCC / GND / TX / RX / PPS). No level shifter is required — the module operates natively at 3.3 V and connects directly to the NM-CYD-C5 LP-UART pins with just 4 wires.

Wiring diagram — 4 wires only:

ATGM336H Module          NM-CYD-C5 (ESP32-C5)
┌────────────┐           ┌──────────────────┐
│        VCC ├───────────┤ 3.3 V            │
│        GND ├───────────┤ GND              │
│         TX ├───────────┤ IO4  (UART1 RX)  │
│         RX ├───────────┤ IO5  (UART1 TX)  │
│        PPS │  (unused) │                  │
└────────────┘           └──────────────────┘

  ⚠️  Power from 3.3 V only — do NOT use the 5 V pin
  ⚠️  TX on the GPS module connects to RX on the ESP (and vice versa)

Signal	ATGM336H pin	ESP32-C5 pin	Notes
Power	VCC	3.3 V	Do not connect to 5 V — module is 3.3 V only
Ground	GND	GND	Common ground required
Data to ESP	TX	IO4 (UART1 RX)	Module transmits NMEA sentences
Data from ESP	RX	IO5 (UART1 TX)	Optional — only needed to send config commands
Timing pulse	PPS	—	Not connected; not used by firmware

Settings: UART1 · 9600 baud · 8N1 · no flow control

The firmware parses GGA sentences for latitude, longitude, altitude, and satellite count, and RMC sentences for fix validity and date/time.

System clock sync: The first valid RMC sentence with an active fix (status = A) sets settimeofday() with the GPS UTC date and time. This corrects the ESP32's clock — which boots at epoch (1970-01-01) — so that files written to the SD card carry accurate FAT timestamps. The sync logic re-applies the time on every incoming RMC sentence until the system year reaches 2024 or later, meaning a late GPS fix (e.g. acquired 60 s into a wardrive) will still correct the timestamps of all files written afterward.

Last-known position persistence: Every valid GGA fix is snapshotted to a g_gps_last_known global. When GPS signal is lost (entering a building, underground parking, etc.) all data-collection features automatically fall back to the last-known coordinates and report an accuracy of 150 m (approximately one city block) in the WiGLE CSV AccuracyMeters field and in GPX waypoints. This ensures wardrive sessions continue collecting data indoors rather than pausing or producing empty location entries.

The last-known position is also written to NVS (keys gps_lat_i, gps_lon_i, gps_alt_i, stored as integer micro-degrees ×10⁶) and reloaded at boot — so even if the first session of the day starts with no GPS fix, the device uses the last outdoor position from a prior session. Writes are throttled to at most once every five minutes to protect NVS flash life (~5+ years at that rate). An explicit save via Settings → GPS Info → Set Position bypasses the throttle.

In addition to the periodic throttled save, the firmware force-saves immediately when GPS lock is lost — detected by an RMC sentence with status = V (void) while current_gps.valid is true. This ensures the most recent fix survives a power cycle even if lock was lost before the next scheduled five-minute write.

Cold start to first fix typically takes 30–60 seconds with a clear sky view.

GPS Info screen status indicator shows one of four states to help with setup and troubleshooting:

Color	Status	Meaning
🟢 Green	Fix: YES	Live satellite fix — all position data current
🟡 Amber	Fix: NO (last known ↓)	Module responding, no current fix; last-known position shown with `*`
🟠 Orange	Fix: NO	Module responding and sending NMEA sentences, but no satellite lock yet
🔴 Red	No GPS module detected	Zero UART bytes received since boot — check wiring or module power

The red "No GPS module detected" state is specifically useful for initial setup: if you see it after wiring the ATGM336H, confirm that TX/RX are not swapped (GPS TX → GPIO 4, GPS RX → GPIO 5), the module is powered at 3.3 V, and the correct UART pins are connected.

Vibrator Motor Circuit

An ERM (eccentric rotating mass) vibrator motor can be added to the NM-CYD-C5 via the onboard SC8002B class-D amp on the SPEAK header (GPIO 26). Two diodes convert the BTL differential output into safe unidirectional motor drive:

Role	Part	Notes
Series rectifier	1N5819 Schottky diode	Anode → VO1 (SPEAK pin 1), cathode → motor +. Half-wave rectifies the BTL output so current flows only in one direction.
Flyback / protection	1N4148 signal diode	Cathode → motor +, anode → motor −. Suppresses back-EMF inductive spikes when the motor stops.
Motor	Mini ERM Vibration Motor	Micro coin or cylindrical ERM, 3 V nominal.
SPEAK header connector	JST GH 1.25 mm 2-pin (HCZZ0015-2)	1.25 mm pitch — the 1.0 mm SH connector is too small and will not fit.

How it works: GPIO 26 drives the SC8002B input with LEDC PWM at 333 Hz / 50% duty (half-wave max = 50% duty). The 1N5819 rectifies the BTL output to give the motor a clean DC-biased drive. The 1N4148 across the motor clamps the inductive kick on every PWM off-cycle. Strength is adjustable 10–100% via Settings → Vibrator Test without reflashing.

Why not drive the motor directly from GPIO: ERM vibrator motors draw 100–200 mA at startup and 50–150 mA running — well beyond the ESP32-C5's safe GPIO limit of ~20 mA continuous (40 mA absolute maximum per pin, ~40 mA total chip budget across all outputs). Connecting a motor directly to a GPIO risks brownout or pin damage. The SC8002B acts as a current-buffered power stage: the GPIO sources only ~1 mA into the amplifier input, while the amp's BTL outputs can deliver up to ~1.5 A peak from the board's power rail. After half-wave rectification at 3.3 V supply (minus ~0.3 V Schottky drop = ~3.0 V motor drive), into a typical small ERM motor (~8–16 Ω), peak pulse current is 200–375 mA and average current at 50% PWM duty is 100–180 mA — roughly 10–15× what a GPIO could safely supply. The 1N4148 flyback diode is essential for the same reason: when the PWM pulse ends the motor's inductance produces a reverse voltage spike that would otherwise be absorbed by (and damage) the SC8002B output.

Circuit photos:

Rectifier circuit closeup — 1N5819 series + 1N4148 flyback

Motor wired to SPEAK header with diode circuit

Assembly wrapped and ready to install

Motor installed in device

3D Printable Cases

The community has designed several enclosures for the NM-CYD-C5 with NM-RF-HAT. All three are designed to fit the full stack — board + RF-HAT + GPS module.

DIP switch access note: Two of the cases below enclose the NM-RF-HAT's DIP switches inside the enclosure, requiring you to open or partially disassemble the case to switch between RF modules. If you plan to switch modules frequently, consider relocating the DIP switches to an external position — solder short extension wires to the switch pads and mount a panel-mount DIP switch on the case exterior — before printing your enclosure.

Case 1 — NM-RF-HAT + CYD2USB + ATGM336H + 18650 Battery

MakerWorld — Case for NM-RF-HAT / CYD2USB / ATGM336H / 18650

Integrates the NM-CYD-C5, NM-RF-HAT, ATGM336H GPS module, and an 18650 lithium cell in a single enclosure. Designed for fully self-contained field use with onboard battery.

18650 cell bay for extended runtime
ATGM336H GPS module compartment
Note: DIP switches may require case access to switch modules

Case 2 — Magnetic Enclosure (6×2mm Magnets)

Printables — CYD NM-RF-HAT Enclosure / Magnetic 6×2mm

Snap-together enclosure using six 6×2mm embedded magnets for tool-free opening. Good balance between protection and module accessibility.

Magnetic lid opens without screws or clips
Clean exterior with access provisions
Note: DIP switches are internal — relocate if switching modules frequently

Case 3 — The Cool One

Thingiverse — CYM-NM28C5 Enclosure

Community favorite. Well-proportioned, solid construction, designed specifically for this project's use case.

Designed with the CYM firmware in mind
DIP switches accessible from exterior — no disassembly required to switch modules

Software Features — Detailed

1. WiFi

The WiFi tile opens a sub-menu grouping all WiFi functions:

Main Menu
├── WiFi
│   ├── Scan & Attack
│   ├── WiFi Attacks
│   ├── Chanalizer
│   ├── WiFi Band Scope
│   ├── Deauth Mon.
│   └── WiFi Observer
├── Bluetooth
│   ├── BT Scan & Select
│   │   └── (select device) → Actions
│   │       ├── BT Locator
│   │       ├── GATT Walker
│   │       ├── Add to BT Lookout
│   │       └── BT Attacks (directed)    ← uses pre-selected device
│   │           ├── Device Spoof
│   │           └── BLE Disconnect
│   ├── BT Attacks                       ← general attacks
│   │   ├── BLE Spam
│   │   └── Device Spoof                 ← loads spooflist.csv
│   ├── BT Observer          ← scan + auto-GATT all visible devices
│   ├── AirTag Scan
│   ├── BT Locator
│   └── Bluetooth Lookout
│       ├── Edit Watchlist
│       └── OUI Groups
├── Wardrive
│   ├── Start Wardrive
│   ├── Options              ← band (2.4/5/Both), raw PCAP toggle, BLE wardrive toggle
│   └── Manage Data         ← CSV file list, upload-log color coding, delete, upload
├── Settings
│   ├── Compromised Data
│   ├── Timing
│   │   ├── WiFi Scan/Ch  (min/max dwell sliders)
│   │   └── GATT Timeout  (3–30 s slider)
│   ├── Download Mode
│   ├── Screen
│   │   ├── Timeout       (inactivity timer)
│   │   └── Brightness    (10–100% overlay)
│   ├── SD Card
│   ├── GPS Info            ← four-state indicator: fix / no-fix / last-known / no module
│   └── Set Position    ← manual lat/lon/alt editor, saves to NVS
├── Power Mode
│   └── Data Transfer
│       ├── AP File Server
│       ├── WiFi Client
│       └── Wardrive Upload
└── Go Dark

WiFi Scan & Attack

Active WiFi scanning with per-network details, followed by targeted attacks on selected networks.

Feature	Description
WiFi Scan	Scans all channels, shows SSID, BSSID, RSSI, channel, encryption. Each network row is color-coded by MFP (Management Frame Protection) status: green = MFP Required (802.11w mandatory), yellow = MFP Capable (optional), red = MFP not supported. At a glance shows which APs are protected against deauth attacks.
Deauth Attack	Sends deauthentication frames to disconnect clients from selected AP. Triggers a 3-second vibrator pulse on launch (requires vibrator hardware).
Evil Twin	Creates a rogue AP cloning the target SSID to lure clients
Captive Portal	HTTP server presenting a custom HTML login page to capture credentials
Handshake Capture	Captures WPA/WPA2 4-way handshakes and saves as PCAP/HCCAPX
ARP Poisoning	LwIP-based ARP spoofing for MitM scenarios

Evil Portal Resources

The Captive Portal, Evil Twin, and Karma AP features all serve HTML pages from /sdcard/lab/htmls/ as the captive login page. Drop any number of .html or .htm files there — each one appears as a selectable option in the portal dropdown when launching an attack. No recompilation needed.

To add portals:

Format your SD card and run SD Card → Provision to create the directory structure
Copy your .html / .htm files directly into /sdcard/lab/htmls/ on the card
Reinsert the card and reboot — all files in that folder appear in the attack portal dropdown
Credentials submitted by victims are appended to /sdcard/lab/eviltwin.txt

The community has built extensive collections of pre-made portals styled to look like ISP login pages, hotel WiFi gates, popular service sign-ins, and more:

Repository	Description
D3h420/Evil-Portals-Collection	Large multi-target collection of portal HTML files — ISPs, hotels, and brands
DoobTheGoober/EvilPortalGenerator	Generator tool for quickly creating custom portal pages from templates
saintcrossbow/Evil-Cardputer-Portals	Portal pages adapted for M5Stack Cardputer; most transfer directly

Note: Files must have a .html or .htm extension to appear in the dropdown. Any filename works — you can keep multiple portals on the card and switch between them per-attack.

Global WiFi Attacks

Attacks that operate on all nearby networks simultaneously.

Feature	Description
Blackout	Mass deauthentication of all detected networks in range
Snifferdog	Channel-hopping sniffer with automatic client deauthentication; exits cleanly and returns radio to normal WiFi scan mode
SAE Overflow	WPA3 SAE authentication flood attack

WiFi Observer & Karma

Passive network intelligence and rogue AP capabilities.

Feature	Description
WiFi Observer	Passive 802.11 sniffing in promiscuous mode — shows APs, associated clients, and probe requests
Karma AP	Automatically responds to client probe requests, creating matching rogue APs

Deauth Monitor

Passive detection of deauthentication attacks happening in the area. Alerts when deauth frames are detected on nearby channels — useful for detecting hostile activity.

Deauth Client

Passive discovery of clients associated with nearby access points — with no association, injection, or attack of any kind. The radio runs in promiscuous mode on each channel, collecting 802.11 data frames to map which client MACs are talking to which BSSID.

The screen shows a scrollable list of discovered clients. Each row displays:

Client MAC address (last 3 octets highlighted)
Associated BSSID (the AP the client is connected to)
Channel and RSSI
Last-seen timestamp

This is recon tooling: identify what's alive on the air, which clients are present, and which AP they belong to — before deciding whether to act. The data is collected entirely passively; the client and AP see nothing from CYM. Logs to /sdcard/lab/deauth/clients_YYYYMMDD_HHMMSS.csv.

Chanalizer

WiFi channel visualization — a 520 px wide portrait-mode channel map showing both 2.4 GHz (ch 1–13) and 5 GHz (ch 36–165) in a single scrollable view. All visible SSIDs are plotted as color-coded bar groups positioned at their operating channel, with a legend showing the group color → SSID mapping.

Auto-scroll: The chart pans left/right automatically (2 px per tick, bouncing at each end) so the full band is always visible without interaction.
Touch drag: Tap and drag to pause auto-scroll and manually scrub to any position. Releasing resumes auto-scroll.
SSID picker: Tap any SSID in the legend to highlight that network's bar across all its channels.
Group color coding: Up to 8 SSID groups are color-coded; legend shows group → SSID mapping.
Channel annotations: Channel numbers annotate the x-axis at correct pixel positions.

WiFi Band Scope

Per-channel RSSI spectrum and waterfall using the WiFi promiscuous radio. Measures peak RSSI of received 802.11 frames per channel — reflects band activity and congestion, not raw RF noise floor.

Band	Channels	Sweep time
2.4 GHz	13 channels (1–13)	~0.8 s
5 GHz	25 channels (36–165)	~1.5 s

The spectrum bar chart (top) shows current peak RSSI per channel as a heat-color bar. The waterfall (bottom) scrolls down one row per completed sweep, building a time history of band activity. Tap Band: 2.4GHz / Band: 5 GHz to toggle — the axis label, peak arrays, and waterfall all reset cleanly on each switch.

ESP-NOW Scout

Passive ESP-NOW device discovery and packet capture using the WiFi promiscuous radio. ESP-NOW is Espressif's low-latency peer-to-peer 802.11 protocol used in smart home devices, RC controllers, sensor meshes, and custom embedded projects. CYM identifies ESP-NOW frames by their exact 5-field fingerprint — FC=0xD0 (Action), Category=0x7F (Vendor Specific), OUI=18:FE:34 (Espressif), Type=0x04 — with no false positives from other 802.11 traffic.

Discovery phase — hops channels 1–13 at 200 ms/channel. Each unique sender appears as a card showing:

Source MAC, destination MAC, channel, RSSI, packet count
First / last seen timestamps
Orange border = unicast (peer-to-peer, likely encrypted) — Cyan border = broadcast (plaintext)
Device label in cyan if matched from profiles.json

Session phase — tap any device card to lock the radio to that channel and open the session sub-screen. The session shows the device's full info, LMK status, and two action tiles:

Tile	Description
This Dev Pkt Log	Captures only frames from the selected source MAC
All Ch Pkt Log	Captures all ESP-NOW frames on the locked channel

Packet log screen — terminal-style dark view showing the last 20 captured frames, scrolled to newest. Each frame shows:

Timestamp (seconds since boot), RSSI, channel, [PLAIN] / [ENC] badge
Full source → destination MACs
Hex dump (first 14 bytes inline, byte count if more)
Broadcast frames: green ASCII interpretation — the raw application payload is immediately readable in plaintext
Unicast + LMK loaded: AES-128-ECB probe — if the decrypted block contains recognisable ASCII, reports DEC✓ + hex; otherwise DEC✗ with a note
Unicast, no LMK: prompt to add key to profiles.json

Buttons: Export TXT saves the full 200-frame ring buffer to /sdcard/lab/espnow/pktlog_YYYYMMDD_HHMMSS.txt (hex + ASCII per frame). Clear resets the ring buffer.

Known-device profiles — place a JSON file at /sdcard/lab/espnow/profiles.json:

[
  { "mac": "AA:BB:CC:DD:EE:FF", "label": "Hat Controller", "lmk": "0102030405060708090a0b0c0d0e0f10" },
  { "mac": "11:22:33:44:55:66", "label": "Hat Hat-1" }
]

lmk is optional (32 hex chars = 16 bytes). Devices without an LMK entry are still discovered and logged; the decrypt probe is skipped.

All output logs to /sdcard/lab/espnow/.

2. Bluetooth

BLE scanning and fingerprinting features leveraging the ESP32-C5's BLE 5.0 radio.

Bluetooth
├── BT Scan & Select    ← start here
│   └── (select device) → Actions
│       ├── BT Locator      (RSSI tracking)
│       ├── GATT Walker     (full GATT fingerprint + JSON output)
│       ├── Add to BT Lookout
│       └── BT Attacks      ← directed attacks on pre-selected device
│           ├── Device Spoof    (clones target MAC + name, no selection needed)
│           └── BLE Disconnect  (flood target with TERMINATE_IND)
├── BT Attacks          ← general attacks (no target needed)
│   ├── BLE Spam        (Apple Prox. Pair / Samsung / Google / Windows / All / AirTag / SmartTag / Sour Apple)
│   ├── Device Spoof    (select from spooflist.csv or add new entry via keyboard)
│   ├── WhisperPair     ← CVE-2025-36911 Fast Pair KBP pairing bypass (detect / probe / exploit)
│   └── BLE Notify Logger (BLE MITM)  ← connects to a target BLE device and logs GATT notifications, reads, and writes
├── BlueDuck            ← BLE HID keyboard injector + DuckyScript engine
│   ├── Script selector (scans /sdcard/lab/ble/blueduck/scripts/)
│   ├── Persona picker  (9 device identities + auto-rotate)
│   └── Live stats      (connects / payloads / disconnects)
├── BT Observer         ← 10 s scan + adv fingerprinting + sequential GATT walk
├── BLE PCAP            ← Kismet PCAPNG; advertising-layer reconstruction from NimBLE reports
├── AirTag Scan
├── Drone Detector
├── BT Locator
├── List Wizard         ← multi-select btsc_*.json files → Unique / Common set ops
├── GATT Profile Snapshots ← browse / view GATT profiles captured by GATT Walker (UI label: Saved Clones)
└── Bluetooth Lookout   ← continuous watchlist monitor
    ├── Edit Watchlist
    ├── Edit Blacklist
    └── OUI Groups

Feature	Description
BT Scan & Select	Active BLE scan — discovers all nearby devices; shows name or vendor (from OUI lookup), RSSI, partial MAC; tap to select a target; Save List saves the full scan to a GPS-tagged JSON file on SD; Rescan restarts the scan in-place; Actions → opens attack tiles on selected target. Devices advertising GATT service `0xFFF6` (Matter Commissioning) are tagged `[M]` — passive detection of Thread/BLE Matter IoT devices with no connection required.
List Wizard	Multi-file BT scan list analysis. Reads all `btsc_.json` files from SD, sorted newest-first. Select up to 4 files, set an optional RSSI threshold, then compute Unique* (devices exclusive to exactly one file, min RSSI) or Common (devices in every selected file, avg RSSI). Results sorted by RSSI descending with a live Change re-filter button; save as new scan file or push to BT Lookout. Per-row delete with confirm dialog.
BT Blacklist	Per-device suppression list at `/sdcard/lab/bluetooth/blacklist.csv`. Any device on the blacklist is silently ignored by BT Scan & Select, BT Lookout, BLE PCAP, and all other BT scan functions. Editor in the BT Lookout screen via the Blacklist button.
BT Observer	Configurable-duration BLE scan (default 10 s, set via Settings → Timing) followed by sequential GATT walks on every discovered device (5 s timeout per device). Results shown in a scrollable live list; tap any row to open the full GATT detail view. Advanced advertising fingerprinting decodes every AD type in each device's advertising payload — company IDs (from Bluetooth SIG assigned numbers), URI schemes, service UUIDs, TX power, flags, and custom manufacturer data. Fingerprint data is appended to the JSON alongside the GATT walk.
BT Locator	RSSI-based proximity tracking of a selected BLE device; updates every 10 s. Vibrator strength scales logarithmically with signal strength — silent below −69 dBm, 10% at −69 dBm, 100% at −40 dBm (requires vibrator hardware).
GATT Walker	Full BLE GATT inspection — walks all services, characteristics, and descriptors; reads attribute values; computes FNV-32 device fingerprint; saves enriched JSON to SD card with service/characteristic names, decoded properties, ASCII data preview, OUI manufacturer, and optional GPS geotag
AirTag Scanner	Passive BLE scan — detects Apple AirTags, Samsung SmartTags, and Tile trackers. Live summary shows four categories. Found Tags list shows type badge, RSSI, Track + GATT Walk buttons per device; Ring button for AirTag (Apple FMN non-owner `{0x01}` confirmed). SmartTag and Tile ring requires owner auth — clearly labeled.
Tag Locator	Per-tag RSSI tracking launched from the AirTag Scan found-tags list
Bluetooth Lookout	Continuous BLE monitor that alerts when a watchlisted device (by full MAC or OUI prefix) is detected nearby. Triggers 3 × 1-second vibrator pulses on each detection (requires vibrator hardware).
BLE Spam	Broadcasts fake BLE advertisements — Apple Prox. Pair (13 device types), Samsung Fast Connect (6 models), Google Fast Pair (12 model IDs), Windows Swift Pair, Apple Find My (AirTag), Samsung SmartTag, Sour Apple (Apple Nearby Action 0x0F — cycles 11 action types to flood iOS with system popups), or All simultaneously
Drone Detector	Dual-mode passive Remote ID scanner (BLE5 extended advertising + WiFi promiscuous 2.4 & 5 GHz). Passively monitors for ASTM F3411-compliant drone Remote ID beacons (DJI, Autel, Parrot, Skydio, …) via ASTM service UUID 0xFFFA; DJI presence via OUI 48:1C:B9 or service 0xFFF0. WiFi side covers NAN channel 6, ODID management IE, and DJI proprietary DroneID vendor IE (OUI 26:37:12). Note: DJI models using OcuSync 4 broadcast Remote ID only on the ground; detection in flight requires an ASTM F3411-compliant transmission. Tap any detected drone to open a detail view with parsed operator ID, UAS serial, location, altitude, and speed. Logs PCAP + JSON to `/sdcard/lab/dronedetect/`.
Device Spoof (directed)	Clones the MAC address and name of a device pre-selected in BT Scan & Select — no additional selection step required
Device Spoof (general)	Loads `/sdcard/lab/bluetooth/spooflist.csv`; select an entry or add new devices via on-screen keyboard, then START to begin spoofing
BLE Disconnect (directed)	Floods a BT Scan & Select pre-selected target with BLE TERMINATE_IND frames to force disconnection
BLE PCAP	Captures BLE advertising packets to SD card in Kismet PCAPNG format (link type 256 — `LINKTYPE_BLUETOOTH_LE_LL_WITH_PHDR`). Packets are reconstructed from NimBLE GAP advertising reports (not raw LL capture). Each Enhanced Packet Block includes a 10-byte pseudo-header: RF channel forced to 37, RSSI, noise floor, and BLE access address. Queue-based write path keeps the SD bus free for the UI. Live packet count shown on screen.
BlueDuck	BLE HID keyboard injector. Pairs with any nearby BLE-capable device, then executes DuckyScript payloads — sending keystrokes as if from a Bluetooth keyboard. Nine built-in device personas (Wireless Keyboard, AirPods Pro, Fitbit, Galaxy Buds, Garmin Fenix, Apple Watch, JBL speaker, Logitech MX Keys, Samsung TV). Auto-rotate mode cycles personas every 5 minutes. Scripts are preloaded into PSRAM at scan time (immune to SD DMA OOM during BLE). HUMAN_MODE with SLOW/NORMAL/FAST variable-speed typing. Full Android (Win+H/B/N), Windows (Win+R/L, Ctrl+Shift+Esc, Win+Shift+S), and iOS (Cmd+H/Space) keyboard shortcut support — 13-script library in `resources/blueduck_scripts/`. Session stats shown live; all events logged to `/sdcard/lab/ble/blueduck/`.
HoneyPair	BLE persona honeypot. Continuously cycles through 9 consumer device personas (AirPods, Galaxy Buds, Garmin watch, etc.), logging every device that initiates a pairing request. Persona MACs are randomised and deduplicated across sessions; auto-rotate every 5 minutes prevents stale scan-response caching. GATT/HID enumeration runs on any device that completes pairing. All events logged to `/sdcard/lab/ble/honeypair/`.
WhisperPair	CVE-2025-36911 Google Fast Pair Key-Based Pairing (KBP) bypass scanner. Passively detects Fast Pair–capable devices during BLE scan (tagged `[FP]` in scan list). Three attack modes: Detect (passive advertisement fingerprinting), Probe (GATT connect + service enumeration, confirms 0xFE2C service presence), and Exploit (writes a crafted AES-128-ECB encrypted KBP packet to trigger unsolicited pairing on vulnerable devices). All results logged to `/sdcard/lab/ble/whisperpair/`. For authorized security research only.

Note: WiFi and BLE share the same radio. Wardrive mode uses hardware coexistence (CONFIG_ESP_COEX_SW_COEXIST_ENABLE=y) to run both concurrently — BLE operates at 12.5% duty cycle (320 ms interval / 40 ms window) to leave WiFi promiscuous mode unimpeded. All other screens use exclusive radio access: switching between WiFi and BLE stops the active radio first via RADIO_MODE_WIFI / RADIO_MODE_BLE.

Drone Detector — How It Works

Drone Detector is a passive Remote ID scanner. It alternates between a WiFi promiscuous phase and a BLE scan phase, looking for the operator ID, UAS serial number, GPS location, altitude, and speed that regulations in most jurisdictions now require drones to broadcast in real time.

Two scan phases run in a continuous loop:

Phase	Duration	What it captures
WiFi promiscuous	10 s	Beacon / management frames on 2.4 GHz ch 1/6/11 + 5 GHz UNII-1 (36/40/44/48) + UNII-3 (149/153/157/161/165)
BLE extended scan	5 s	BLE 5.0 extended advertising on 1M + Coded PHY (legacy 1M-only fallback when extended adv is unavailable)

What gets detected:

Signal	Standard / Source	Decodes
BLE service UUID `0xFFFA` service-data AD	ASTM F3411 (all compliant brands — DJI, Autel, Parrot, Skydio, Holy Stone, …)	Full Remote ID message: operator ID, UAS serial, location, altitude, speed, timestamp
BLE manufacturer data, company `0x0E00`, code `0x0D`	Legacy OpenDroneID alternate form	Same as above
BLE OUI `48:1C:B9` or service UUID `0xFFF0`	DJI presence beacon (extended advertising)	Labels "DJI drone (BLE)"; RID payload parsed if included
WiFi beacon ODID management IE `0xFA 0x0B 0xBC`	ASTM F3411 over WiFi	Full Remote ID message
WiFi NAN SDF frame, service `50:6F:9A`	NAN-based Remote ID	Full Remote ID message
WiFi vendor IE `0xDD`, OUI `26:37:12`	DJI proprietary DroneID	Presence + 16-byte ASCII serial; lat/lon best-effort (GPS decode untested on hardware)

Important caveat — airborne DJI detection: The DJI Mini 4 Pro (and other recent DJI models using OcuSync 4) do not broadcast standard OpenDroneID in flight. Their Remote ID is embedded in the encrypted OcuSync 4 link, which is not decodable by the ESP32 or commodity SDR hardware. CYM will detect these drones on the ground via their BLE pairing/presence beacon. A drone with a standards-compliant Remote ID (required by ASTM F3411 / EU 2019/945) will be detected at range in both phases.

Detail view:

Tap any row in the drone list to open a detail screen showing all decoded fields for that drone:

UAS ID / operator ID / serial number
Location (lat, lon), altitude (m), speed (m/s), heading
ID type, category, classification
Source (BLE / WiFi), RSSI, packet count, last seen

Output logs saved to /sdcard/lab/dronedetect/:

drone_YYYYMMDD_HHMMSS.pcap — raw BLE advertising packets (Kismet PCAPNG format)
drone_YYYYMMDD_HHMMSS.json — parsed Remote ID records for all detected drones

Drone Spoof — How It Works

Drone Spoof broadcasts a synthetic ASTM F3411 Remote ID beacon, making a receiver see a drone that does not physically exist. Use cases: testing Remote ID receiver software, authorized counter-UAS research, drone regulation compliance validation, and RF lab research.

Configurable fields:

Field	Description
UAS ID	20-byte drone serial / operator identifier
Operator ID	20-byte operator string
Latitude / Longitude	GPS coordinates of the spoofed position
Altitude	Barometric / GPS altitude in meters
Speed / Heading	Ground speed (m/s) and horizontal heading (deg)

Broadcast modes:

BLE — Extended advertising on primary PHY 1M, secondary PHY 1M. Broadcasts ASTM F3411 service UUID 0xFFFA with a valid Remote ID message in the service-data AD. Received by any compliant Remote ID receiver.
WiFi — Management frame beacon with ODID IE (type 0xFA 0x0B 0xBC). Reaches receivers monitoring channel 6 or the configured channel.

For authorized research only. Broadcasting a false Remote ID identifying a drone you do not operate may be illegal under your local aviation regulations. Ensure you have explicit authorization before transmitting outside of a shielded lab environment.

BT Scan & Select — How It Works

Step 1 — Scan: Open BT Scan & Select from the Bluetooth menu. An active BLE scan runs (duration configurable via Settings → Timing → BT Scan, default 10 s), collecting all advertising devices. Each row shows device name (or vendor from OUI lookup, or [Unknown]), RSSI, and the last 3 octets of the MAC address. The list updates live every 500 ms during the scan.

Step 2 — Select: Tap any row to select a target device. The row highlights in cyan and the status bar shows the selection. Tap again to deselect. Only one device can be selected at a time. Scrolling the list does not select a device — only a clean tap (no scroll movement) counts as a selection.

Step 3 — Actions: Once a device is selected, tap Actions → to open the action tile screen. Available actions: BT Locator (RSSI proximity tracking), GATT Walker (full GATT inspection and JSON output), and Add to BT Lookout (add the device MAC to the continuous watchlist). The target name or MAC is shown in the screen title.

Bottom button row (always visible, no device selection needed):

Exit — stop scan and return to Bluetooth menu
Save List — opens a label dialog; writes the full scan list to SD as a numbered JSON file
Rescan (amber) — stops the current scan, clears the device list, and immediately starts a fresh scan at the configured duration
Actions → (cyan, appears after device selection) — opens attack tile screen for the selected target

Save List — File format

Scan files are saved to /sdcard/lab/bluetooth/scans/. The filename encodes a monotonically-incrementing scan counter (NVS-persisted across reboots), the UTC time, GPS coordinates if available, and the user label:

btsc_00001_HHMMSS_LAT_LON_label.json   (with GPS — live or last-known)
btsc_00001_HHMMSS_label.json           (no GPS ever recorded)

GPS location uses the persistent GPS subsystem: gps_best() returns the live fix when available, or the last-known location (saved to NVS on each valid fix and on shutdown) when GPS signal is lost. You always get the closest known position even after a dropout.

JSON schema:

{
  "label": "JBL",
  "timestamp": "143022",
  "datetime": "2026-05-20 14:30:22",
  "gps_lat": 37.4219984,
  "gps_lon": -122.0840012,
  "gps_alt": 12.3,
  "gps_live": true,
  "fw_version": "v1.6.54",
  "scan_id": 3,
  "device_count": 12,
  "devices": [
    {
      "mac": "AA:BB:CC:DD:EE:FF",
      "addr_type": 0,
      "phy": 1,
      "rssi": -62,
      "name": "JBL Flip 6",
      "company_id": 0,
      "is_airtag": false,
      "is_smarttag": false,
      "is_possible_airtag": false,
      "is_fast_pair": false
    }
  ]
}

Field	Description
`label`	User-supplied label (alphanumeric + `-_`, defaults to `mark`)
`timestamp`	`HHMMSS` UTC — used in filename
`datetime`	`YYYY-MM-DD HH:MM:SS` UTC from GPS-synced system clock
`gps_lat/lon/alt`	GPS coordinates — live fix or last-known persistent position
`gps_live`	`true` if GPS was live at save time; `false` if using last-known
`scan_id`	Monotonically increasing counter (NVS-persisted) — matches `%05u` prefix in filename
`device_count`	Number of entries in `devices[]`
`rssi`	Peak RSSI seen during scan (dBm)
`addr_type`	0 = public, 1 = random
`phy`	1 = 1M, 2 = 2M, 3 = coded

List Wizard — How It Works

List Wizard reads all saved btsc_*.json scan files from /sdcard/lab/bluetooth/scans/ and lets you compare them across sessions.

File list: Files are displayed newest-first (by scan counter). Each row shows the user label, the full save date and time (YYYY-MM-DD HH:MM), and the device count. A small red trash button on the right of each row deletes the file after a confirm dialog.

Selection: Tap up to 4 rows to select them (highlighted cyan). The status bar shows how many are selected.

RSSI Threshold popup: Before computing a set operation, tap Unique or Common to open the RSSI threshold popup. A slider from −99 dBm (no filter, default) to 0 dBm lets you exclude weak/distant devices.

Set operations:

Unique (cyan) — devices exclusive to exactly one of the selected files. A device that appears in two or more files is excluded. RSSI shown is the minimum (signal floor) across all sightings of that device.
Common (green) — devices present in every selected file. RSSI shown is the average across all sightings in all selected files.

Result overlay: A scrollable list sorted by RSSI descending. Each row shows RSSI MAC Name. An orange RSSI bar at the top shows the active threshold with a Change button — tap it to open the threshold slider and instantly re-filter without re-reading the SD card (the accumulator stays live in PSRAM for the lifetime of the result overlay).

Bottom button row in result overlay:

Close — dismiss the overlay, return to file list
New List — opens a label dialog and saves the result as a new btsc_*.json scan file (same format as BT Scan & Select)
Lookout — appends all result MACs to /sdcard/lab/bluetooth/lookout.csv and reloads the BT Lookout watchlist

BT Blacklist

The blacklist at /sdcard/lab/bluetooth/blacklist.csv contains devices that should be globally suppressed. Any device whose MAC (or OUI prefix if oui_only=1) appears in the blacklist is silently skipped by BT Scan & Select, BT Lookout, BLE PCAP, and all other BT scan paths.

CSV format (same as lookout.csv — no header row):

AA:BB:CC:DD:EE:FF,0   # full MAC match
AA:BB:CC,1            # OUI prefix match (first 3 octets only)

The editor is in the BT Lookout screen — tap the Blacklist button (dark red, below the Edit List / OUI Groups row). Rows are shown in a scrollable list with a delete button on each entry and an Add button for new entries.

Multi-Session Counter-Surveillance Workflow

Use BT Scan & Select + List Wizard to detect whether a specific person or vehicle is carrying a fixed-MAC BLE tracker — an AirTag, Oura Ring, Fitbit, Garmin watch, or any other BLE device that does not randomize its MAC. The technique is simple: scan the same target environment twice and look for devices that appear in both sessions.

Step 1 — First scan

Open BT Scan & Select from the Bluetooth tile. Let the scan run for the configured duration (default 10 s; increase to 30 s in Settings → Timing for better coverage). When done, tap Save List, enter a descriptive label (e.g. coffee_shop_1030), and tap Save. The file is written to /sdcard/lab/bluetooth/scans/.

Step 2 — Second scan (different time or location)

Move to a second location — or wait for the target to leave and return — then scan again. Save with a new label (e.g. coffee_shop_1430). Any legitimate ambient device (smart speaker, neighbor's phone) should not appear in both scans. A tracker that follows the person will.

Step 3 — Common device analysis

Open List Wizard from the Bluetooth tile. Select both saved scan files (tap each row to highlight cyan). Optionally raise the RSSI threshold to exclude weak devices you were not physically near. Tap Common.

List Wizard returns every device that appeared in both scans. Sort by RSSI descending — devices near the top were strong, nearby, and consistent across sessions.

Step 4 — Identify the tracker

Look for devices with recognizable characteristics:

Device	MAC behavior	How to spot
Apple AirTag	Rotates every ~24 h when not near owner	Name `AirTag`, manufacturer `Apple`, `is_airtag: true` flag; detected directly by AirTag Scanner
Samsung SmartTag	Rotates periodically	SmartThings Find service `0xFD5A` in adv data; AirTag Scanner shows type badge `SmartTag`
Tile tracker	Static MAC	Service UUID `0xFEED` in advertisement; AirTag Scanner shows type badge `Tile`; static MAC makes it ideal for List Wizard cross-session matching
Oura Ring	Static MAC	OUI `70:C8:8B` (Oura Health) or name `Oura Ring`
Fitbit	Static MAC	OUI `E8:AB:F3` / `EC:5C:68` (Google/Fitbit) or name `Charge`, `Versa`, `Sense`
Garmin watch	Static MAC	OUI `C4:5A:B1` / `58:93:D8` (Garmin) or name `fenix`, `vivosmart`
General fixed-MAC	Static	Same full MAC across both sessions; not in OUI Groups above

Devices that rotated their MAC between sessions will not appear in Common — they are not reliable tracking vectors.

Step 5 — Add suspects to BT Lookout

In the result overlay, tap Lookout to append all Common results to the BT Lookout watchlist. Then open Bluetooth Lookout and tap Start. From this point, any time the suspected tracker comes within BLE range, the device fires 3 × 1-second vibrator pulses and shows a popup with the device name, MAC, vendor, and RSSI.

Tips

Set the RSSI threshold to −70 dBm or higher to exclude devices that were only marginally visible (passers-by, parked cars one block away).
If the target is a vehicle, scan the same parking lot or route. BLE range is ~10–30 m — you need to be near the vehicle for the tracker to register.
Use the New List button to save the Common result as a new scan file for later reference or comparison against a third session.
OUI Groups in BT Lookout lets you monitor all devices from a specific manufacturer (e.g. all Garmin OUIs) without needing a specific MAC — useful when the tracker may have cycled its address.

Tracker Scanner (AirTag / SmartTag / Tile) — How It Works

The Tracker Scanner and Tag Locator work together to let you detect and locate hidden tracking devices using only the NM-CYD-C5 — no phone required. Three tracker families are supported: Apple AirTag, Samsung SmartTag, and Tile.

Step 1 — Scan

Open AirTag Scan from the Bluetooth tile. The device switches the radio to BLE and begins a continuous passive scan. Detections are categorized by tracker type and updated live:

AirTags:          2
AirTag? (Prox):   1
SmartTags:        1
Tiles:            1

Other BT Devices: 14
Total BT devices: 19

AirTag? (Prox) — AirTags in owner-proximity mode: the owner's iPhone is nearby, so the tag is advertising with a Nearby Action 0x05 payload instead of the Find My type byte. These are real AirTags but their anti-stalking audio has been suppressed by proximity to the owner.

The scan runs continuously in the background after the first detection. Counts always reflect unique devices, not raw advertisement packets — the same device sending many ads registers as one device.

Once at least one tracker is found the View Found Tags button appears.

Step 2 — View Found Tags

Tap View Found Tags to open a scrollable list of every detected tracker. Each entry shows:

Type badge (orange AirTag, cyan SmartTag, teal Tile, yellow AirTag?)
MAC address (last 3 octets shown, full MAC for GATT connect)
Device name (if advertised — SmartTag reads "Searching..." when unowned)
Last seen RSSI in dBm
Track button — starts RSSI proximity tracking
Ring button or auth note — see per-tracker table below
GATT Walk button — full GATT inspection saved to /sdcard/lab/gatt/

Per-tracker ring support:

Tracker	Ring	Notes
Apple AirTag	Yes — `{0x01}` non-owner trigger	Apple FMN service `7DFC9000-7D1C-4951-86AA-8D9728F8D66C`, char `7DFC9001-...` (Write + Response). Single byte `{0x01}` triggers the anti-stalking locator tone without any auth. Apple deliberately designed this path so anyone who finds an unwanted AirTag can identify it. The tone is quieter than an owner-initiated ring.
Samsung SmartTag	No — "No ring / owner auth req"	Uses Samsung Find My Mobile protocol (BLE service `0xFEF3` + SmartThings `594a34fc-...`). Commands require Samsung account authentication. Does not implement Apple FMN despite superficially similar advertising. GATT walk confirmed: char `00000100-0004-1000-8000-001a11000101` (Write) is present but requires a signed session from Samsung's servers. Device name reads `Searching...` when not bound to an owner account.
Tile	No — "No ring / owner auth req"	Tile BLE protocol (service `0xFEED`): command char `9D410018-35d6-f4dd-ba60-e7bd8dc491c0` (Write No Response) accepts writes but they must be signed with the owner's account key issued by Tile's cloud. Sending unauthenticated bytes (including `{0x01}` and `{0x08, 0x01}`) is silently ignored. Tile's MAC is static — it does not rotate — which is useful for tracking and List Wizard correlation.

Step 3 — Ring an AirTag

Tap the Ring button on an AirTag Found Tags entry. CYM connects via BLE and sends a single-byte write to the Apple FMN sound characteristic (7DFC9001). Within a few seconds the AirTag emits its locator chirp. A status popup shows progress (Connecting... → Writing... → Done — listen for chirp). The ATT error code is translated on failure (e.g. ATT err 0x08 = Insufficient Authorization). Only AirTags implement this open path — SmartTag and Tile show an auth note in place of a Ring button.

Step 4 — Track

Tap Track on any device. The firmware locks onto that device's MAC address and starts the BT Locator tracking task, which rescans for that specific MAC every ~10 seconds and updates the live RSSI reading on screen.

Use the RSSI value to home in on the tag — a higher (less negative) number means you are closer:

RSSI	Approximate distance	Vibrator strength
-40 dBm or stronger	Very close (within ~1 m)	100%
-55 dBm	Nearby (~1-3 m)	~58%
-69 dBm	~5 m range edge	10% (threshold)
Below -69 dBm	Far away or obstructed	Silent

Vibrator strength updates every 500 ms and scales linearly with dBm (which is already a log-scale of power), giving a natural haptic proximity feel. The strength used by Settings -> Vibrator Test is saved on entry and fully restored when you exit the locator.

AirTag Far Away

AirTag Found

Tap Exit at any time to stop tracking and return to the main menu. The radio switches back to WiFi mode automatically.

Step 5 — GATT Walk any tracker

Tap GATT Walk on any Found Tags entry to connect and enumerate the device's full BLE service tree. The output is saved to /sdcard/lab/gatt/ as a timestamped JSON with FNV-32 fingerprint filename. Useful for:

Confirming ring characteristic handles and properties
Reading the device's reported firmware version and serial number
Identifying which authentication services are present
Building known-device profiles for future tracking correlation

GATT Walker — How It Works

GATT Walker — live progress during a BLE inspection walk

GATT Walker connects to a selected BLE device and performs a full GATT inspection — enumerating every service, characteristic, and descriptor, reading all readable attribute values, and saving the result as a structured JSON file on the SD card.

Why GATT walk a device?

Reading a device name is just the surface. A full GATT walk is one of the richest passive fingerprinting and intelligence-gathering techniques in the BLE space.

Rolling MAC defeat. Modern BLE devices randomize their advertising MAC every 7–15 minutes (iOS, Android, and Windows all do this). The GATT service/characteristic layout does not rotate — it is fixed per device model and firmware version. The FNV-32 fingerprint computed over the ordered set of service and characteristic UUIDs creates a stable device signature that survives MAC rotation entirely. Two captures with different MACs but matching fingerprints are almost certainly the same physical device. Combined with System ID (0x2A23) — which is derived from the Bluetooth address and does not rotate — and Serial Number (0x2A25), you get a tracking signature more robust than the advertising MAC.

Gratuitous information leakage. Many devices expose the Device Information Service (0x180A) completely unauthenticated:

Characteristic	UUID	What leaks
Manufacturer Name	0x2A29	Brand + sometimes ODM source
Model Number	0x2A24	Exact device model
Serial Number	0x2A25	Unit-level identifier — unique per device
Firmware Revision	0x2A26	Exact build — maps to known CVEs
System ID	0x2A23	Derived from BT address — stable across MAC rotation
PnP ID	0x2A50	Bluetooth SIG vendor + product ID

Vendor-specific services (0xFF00+) are where IoT devices hide configuration registers, telemetry, WiFi SSIDs (and on some early/cheap devices, plaintext WiFi passwords), OTA firmware update channels, and debug/diagnostic services left enabled in production firmware. Descriptor labels (0x2901) are written by vendors for internal tooling and frequently left in production — strings like "factory_reset_trigger" or "debug_uart_passthrough" appear in the clear.

Commercial tracking infrastructure. Google Fast Pair (0xFE2C), Microsoft Swift Pair, Tile, and AirTag-style trackers all have fixed GATT service layouts regardless of rotating MACs. The service layout alone identifies which tracking network a device belongs to and often reveals the device model.

Security posture assessment. A GATT walk immediately reveals which characteristics require authentication or encryption versus which are open. A writable control characteristic that requires no pairing is a weak security model regardless of what it controls — useful for auditing devices before deployment.

Subscription data layer. A static GATT read only captures what the device holds at that moment. Characteristics with N (Notify) or I (Indicate) properties only push data to subscribed clients — heart rate sensors, glucose monitors, environmental sensors, and wearables stream live telemetry only after a client writes 0x0001 to the associated CCCD descriptor (0x2902). This is the layer a passive walk alone never sees.

Workflow:

Open BT Scan & Select, let the scan run, tap a device to select it.
Tap Actions →, then GATT Walker.
The active BLE scan stops automatically and a GATT connection is initiated to the target.
The screen shows live progress through the walk stages:

Connecting...
Connected, discovering services...
Chr discovery: svc 2/5
Discovering descriptors...
Reading characteristics...
Saving results...
Walk complete

When complete, the screen automatically transitions to a full scrollable detail view showing the entire GATT tree: MAC + OUI vendor, FP, GPS, per-service UUID + name, per-characteristic UUID + name, decoded property flags, hex data, and ASCII preview.

Output file: /sdcard/lab/gattwalker/YYYYMMDD_HHMMSS_AABBCCDDEEFF_gattwalk.json

{
  "version": 1,
  "timestamp": "20260429_142233",
  "mac": "AA:BB:CC:DD:EE:FF",
  "addr_type": 0,
  "name": "My BLE Device",
  "manufacturer": "Texas Instruments",
  "rssi": -67,
  "gps": { "valid": true, "lat": 37.1234567, "lon": -122.4567890 },
  "fingerprint": "0xA3F1C2B0",
  "services": [
    {
      "uuid": "0x1800",
      "name": "Generic Access",
      "start_handle": 1,
      "end_handle": 8,
      "characteristics": [
        {
          "uuid": "0x2A00",
          "name": "Device Name",
          "def_handle": 2,
          "val_handle": 3,
          "properties": 2,
          "props_str": "R",
          "read_data": "4D7920446576696365",
          "ascii": "My Device"
        }
      ]
    }
  ]
}

Fingerprint: An FNV-32 hash computed over all service UUIDs, characteristic UUIDs, and property flags in walk order. Identical device models typically produce the same fingerprint, making it useful for passive device-type identification across multiple captures.

GPS geotagging: GATT Walker uses the best available GPS position — live fix if locked, last-known fallback if not (see GPS Info & Fallback Position). The JSON gps.valid field is true whenever any position is available (live or stale). When the fallback position was used, the coordinates are still useful for approximate area-level mapping; the 150 m stale accuracy is reflected in the surrounding context even though the JSON does not currently include an accuracy field.

Characteristic Properties (props / props_str): Each characteristic has a bitmask that declares what operations it supports. The JSON includes both the raw integer ("properties") and the decoded string ("props_str"). The on-device result screen shows both the compact flag string and the full human-readable expansion, e.g. Props: R N (Read, Notify).

GATT Walker detail view — service tree with decoded properties and ASCII data

Bit	Hex	Flag	Meaning
0	`0x01`	BC	Broadcast — value can be included in advertising packets
1	`0x02`	R	Read — current value can be read
2	`0x04`	WNR	Write No Response — fire-and-forget write, no acknowledgement
3	`0x08`	W	Write — acknowledged write; server confirms receipt
4	`0x10`	N	Notify — server pushes updates to subscribed clients (no ACK)
5	`0x20`	I	Indicate — server pushes updates; client must ACK each one
6	`0x40`	AS	Authenticated Signed Write — write with MITM-protected signature
7	`0x80`	EX	Extended Properties — additional properties stored in descriptor `0x2900`

Common combinations:

Props string	Raw	Typical use
`R`	`0x02`	Read-only sensor or config value
`R N`	`0x12`	Live sensor — read current value + subscribe for streaming updates
`R I`	`0x22`	Like notify but reliable — server waits for client ACK
`R W`	`0x0A`	Read/write configuration register
`WNR`	`0x04`	Command channel — write commands with no response needed
`R W N`	`0x1A`	Full-featured — read, write, and subscribe

Tip: To receive live streaming data (e.g. a heart rate sensor), look for characteristics with N (Notify) or I (Indicate). A CCCD descriptor (0x2902) is always present alongside these and is what a client writes to in order to enable or disable the subscription.

BLE data limits: The Bluetooth Core Specification sets a hard ceiling of 512 bytes per attribute value. The firmware negotiates the maximum possible ATT MTU on every connection so that large attributes are captured in full rather than truncated at the BLE default of 20 bytes.

Limit	Value	Source
Max attribute value	512 bytes	BLE Core Spec — hard ceiling
Default ATT MTU payload	20 bytes	BLE spec default (no negotiation)
Max ATT MTU payload	514 bytes	BLE spec maximum
Firmware capture buffer	512 bytes	`GW_READ_MAX` — matches spec ceiling

Attributes longer than one MTU are read automatically in multiple chunks (ATT_READ_BLOB_REQ chaining). GW_READ_MAX = 512 is therefore the correct and final limit — no BLE device can legitimately send more than 512 bytes per characteristic.

Walk limits: Up to 20 services, 16 characteristics per service, 6 descriptors per characteristic. PSRAM-allocated (~250 KB result struct + 128 KB JSON buffer).

Connect timeout: Configurable via Settings → Timing → GATT Timeout (3 s – 30 s slider, NVS-persisted). The default is 30 s. Use a shorter value for fast nearby devices; leave it long for distant or slow-to-respond targets. BT Observer uses a fixed 5 s timeout (not user-adjustable).

Note: GATT Walker connects to the target — it is an active, deliberate inspection, not passive. The target device will see an incoming connection. Cancel at any time with the Cancel Walk button; the connection is cleanly terminated.

BT Observer — How It Works

BT Observer automates the scan-then-walk workflow: it runs a configurable-duration active BLE scan (default 10 s, set via Settings → Timing → BT Scan), captures all discovered devices, then attempts a sequential GATT walk on each one (5 s connect timeout). Results are displayed in a live scrollable list and saved as JSON files to /sdcard/lab/gattwalker/ — identical format to manual GATT Walker.

Advanced advertising fingerprinting is applied during the scan phase. For every device, the raw advertising payload is parsed AD type by AD type:

Flags (0x01) — LE General/Limited Discoverable, BR/EDR Not Supported
Company ID (0xFF) — looked up against the Bluetooth SIG assigned-numbers list; company name written to JSON alongside the raw bytes
Complete/Incomplete UUID lists (0x02–0x07) — all 16-, 32-, and 128-bit service UUIDs decoded
TX Power Level (0x0A) — power at source in dBm; useful for path-loss estimation when combined with RSSI
URIs (0x24) — scheme prefix decoded (http/https/ftp etc.) and full URI reconstructed
Manufacturer-specific data — raw hex + ASCII, company ID noted

All decoded AD data is appended to the per-device JSON under "adv_data" before the GATT walk starts, so the file contains both the advertising fingerprint and the live GATT profile in one document.

Workflow:

Open BT Observer from the Bluetooth tile.
The device starts an active BLE scan (default 10 s). Discovered devices appear in the list with name/vendor and RSSI. AD fingerprinting runs concurrently as advertisements are received.
After the scan window closes, the observer walks each device in turn. The list updates live as each walk completes: green checkmark with service/chr counts on success, red on failure.
When all devices have been attempted (or the session is stopped), the status bar shows total enumerated count.
Tap any row with a successful walk to open the full GATT detail view (same scrollable tree as the single-walk result screen).

Key differences from manual GATT Walker:

	GATT Walker	BT Observer
Target	One device (selected)	All devices in one scan session
Connect timeout	Configurable (3–30 s, NVS)	Fixed 5 s per device
Result screen	Auto-navigates to detail on complete	Tap-to-open per device
Scan pass	Continuous (relies on existing scan)	Single scan burst (10–30 s, configurable), no re-scan

Per-device JSON files are saved using the same /sdcard/lab/gattwalker/ path and enriched format as single walks (manufacturer, service/chr names, props_str, ascii).

GATT Walker — Extended Probe (CCCD Subscription)

The static walk captures every readable attribute value at the moment of connection. Extended Probe goes one layer deeper: after the walk completes, it reconnects to the target and iterates every characteristic with N (Notify) or I (Indicate) in its property flags, writes 0x0001 (or 0x0002 for Indicate) to the associated CCCD descriptor (0x2902), and collects whatever the device pushes back during the listen window. This is the live telemetry layer — heart rate streams, sensor readings, status updates — that a read-only walk never sees.

How to run it:

From the GATT result screen, tap the red Ext. Probe button at the bottom. The firmware reconnects to the same device, walks every N/I characteristic in sequence with an 8-second listen window each, then re-saves the JSON with the captured notification frames appended inline. A dedicated probe progress screen shows which characteristic is being subscribed in real time.

The probe only writes to CCCD descriptors — it never writes to value handles directly.

JSON enrichment:

The subscription data is written back into the same JSON file as a "probe" key on each characteristic that was attempted. Characteristics with no N/I flag are unchanged:

{
  "uuid": "0x2A37",
  "name": "Heart Rate Measurement",
  "props_str": "N",
  "read_data": null,
  "ascii": null,
  "probe": {
    "cccd_written": true,
    "notify_count": 4,
    "notify_data": [
      "0048",
      "0049",
      "004B",
      "004A"
    ]
  }
}

Each string in notify_data is the raw bytes of one notification frame, concatenated as hex without separators (e.g. "0048" = flags byte 0x00 + heart rate 72 BPM). read_data and ascii are null for notify/indicate-only characteristics that cannot be directly read.

This keeps all data from a device in a single enriched file — the initial static snapshot plus the live subscription layer — indexed by the same FNV-32 fingerprint for cross-session correlation.

Handle gap scan (stretch goal): After the named service walk, probe attribute handles in the gaps between declared service ranges. Some devices hide characteristics from service discovery but still respond to direct handle reads. Any responding handles are appended to the JSON under "hidden_handles".

GATT Interactive — Live Read / Write / Subscribe

After a GATT walk completes, the connection is held open for interactive use. From the GATT result screen, tap any characteristic row to open the Interactive popup — a modal control panel for that single attribute.

Available actions in the popup:

Button	What it does
Read	Issues a GATT Read Long on the value handle; result appears in the log textarea below
Subscribe	Writes `0x0001` to the CCCD descriptor and streams incoming notifications to the log. Tap Unsubscribe to cancel.
Bond	Initiates BLE bonding with the connected device (SMP pairing). Use when the characteristic requires an authenticated link.

The log textarea auto-scrolls as data arrives. Each entry is timestamped and shown as hex + ASCII (printable bytes decoded inline). Results are also appended to the device's JSON on SD card so the session stays in one enriched file.

Connection lifecycle: The walk sets the device keep-connected, so the link is alive as soon as the result screen appears. The connection is torn down cleanly when you navigate away or exit the result screen.

Write support: The popup currently exposes Read and Subscribe. A write field (hex input → GATT Write Command / Write Request) is planned for a future release.

GATT HID Decoder

If the connected device advertises the HID service (0x1812) the GATT result screen shows a HID button in the bottom control bar (green). Tapping it opens the HID Decoder — a live input monitor that:

Parses the HID Report Map (0x2A4B) — walks each item tag decoding Usage Page, Usage, Report Size, Report Count, and Input/Output/Feature tags. The parsed report structure is shown as a scrollable summary.
Subscribes to all input reports (0x2A4D) — each incoming notification is decoded against the parsed map and displayed. For HID boot protocol devices (keyboards, mice) the decoder understands the 8-byte boot report format: modifier byte, reserved byte, and up to 6 simultaneous key codes. Key codes are translated to ASCII or named keys (Ctrl, Shift, Alt, arrows, F1–F12, etc.).
Logs to SD card — all decoded input events are written to /sdcard/lab/ble/hid/hid_YYYYMMDD_HHMMSS.jsonl in JSONL format (one JSON object per input event).

The HID decoder is read-only — it subscribes to input reports but does not inject any HID output. It is designed for passive device analysis and verification that a HID peripheral is functioning correctly.

Saved GATT Clones

GATT Clone (the purple Clone button on the GATT result screen) saves a full snapshot of the connected device's GATT profile to SD card as a clone file (/sdcard/lab/ble/clones/clone_YYYYMMDD_HHMMSS.json). The clone includes:

Device name, address, address type, OUI manufacturer, FNV-32 fingerprint
All services, characteristics, and descriptor handles with their UUIDs and values read at clone time

GATT Profile Snapshots (accessible from the Bluetooth menu tile as "Saved Clones") browses all saved profile snapshot files. Each row in the list shows the device name/MAC and the capture timestamp. Tap any row to:

View the full GATT profile offline (no device connection needed)
Re-identify a device by comparing its fingerprint against new scans

Snapshots persist across reboots and can be exported from the SD card for offline analysis. They are stored in standard JSON — identical format to GATT Walker output — and are compatible with any JSON tooling. Note: a GATT profile snapshot captures the attribute tree, values, and fingerprint at a point in time; it is not a full operational device emulation.

BLE Notify Logger (BLE MITM)

Current implementation: BLE MITM connects to the target BLE device as a GATT client and logs notifications, indications, and attribute reads from that device. The full two-sided transparent proxy described below (steps 2-3) is the target design; verify against the installed firmware version for current relay capability.

BLE MITM (in BT Attacks) connects to a selected BLE device and logs GATT traffic — reads, writes, and notifications — from that device to SD card. Full relay mode: CYM inserts itself between two BLE peers, proxying GATT traffic in both directions while logging every exchange.

How it works:

CYM connects to the target (server) device as a normal GATT client, keeping the link open.
CYM simultaneously advertises as a clone (peripheral) using the target's device name and a randomised address.
Clients that connect to the clone see the real GATT profile — CYM forwards all requests upstream and returns the live responses downstream.
Every GATT exchange in both directions is written to /sdcard/lab/ble/mitm/mitm_YYYYMMDD_HHMMSS.jsonl — direction, handle, UUID, value (hex + ASCII), and timestamp.

What it captures: All readable attribute values at connection time, all writes from clients, and all notifications/indications from the server. Encrypted characteristics that require bonding are captured as opaque bytes unless CYM holds the peer LTK.

Usage: Select a target device in BT Scan & Select, then navigate to BT Attacks → BLE MITM. The target MAC is pre-populated. Tap Start to begin proxying; the screen shows a live log of proxied frames. Tap Stop to tear down both connections cleanly.

For authorized security research and device debugging only.

Bluetooth Lookout — How It Works

Bluetooth Lookout runs a continuous background BLE scan and alerts you — visually and via NeoPixel LED — any time a watchlisted device is seen nearby. Useful for detecting known surveillance hardware, trackers, or specific devices by MAC address or manufacturer OUI prefix.

Watchlist: Devices are stored in /sdcard/lab/bluetooth/lookout.csv. The file is auto-created on first use (parent directories created automatically). Add devices three ways:

BT Scan & Select → Add to Lookout — scans for BLE devices, select one, choose "Add to Lookout". The exact MAC is added.
OUI Groups (see below) — adds all devices from a predefined manufacturer OUI block in one tap.
Edit List → + OUI — manually type any 3-byte OUI (formats AA:BB:CC, AABBCC, or AA-BB-CC) and an optional label. Saved as an OUI-prefix entry that matches any device from that manufacturer.

Matching modes:

Full MAC — triggers only when that exact 6-byte address is seen. Best for tracking a specific known device.
OUI prefix — triggers when any device from that manufacturer's OUI block (AA:BB:CC:*:*:*) is seen. Best for detecting a category of hardware (e.g., any Axon body camera in range).

Alert: When a match is found the NeoPixel flashes red (3 × 250 ms on/off), the vibrator fires 3 × 1-second pulses (requires vibrator hardware), and a popup appears on screen showing the device name, MAC address, vendor (if OUI database is loaded), and RSSI. A 30-second per-device cooldown prevents repeated alerts for the same device.

Controls on the Lookout screen:

Button	Action
Start / Stop	Toggle the continuous BLE scan loop
Blackout	Dim the screen to black while monitoring continues in the background
Edit List	Open the watchlist editor — mark entries for deletion, then Save
OUI Groups	Add predefined law-enforcement / tracking hardware groups to the watchlist

OUI Groups

OUI Groups (accessible from the Bluetooth Lookout screen) lets you add entire manufacturer OUI blocks to the watchlist in one tap. The firmware will then alert whenever any BLE device from that manufacturer is detected.

Pre-loaded groups:

Group	OUI Prefix(es)	Category
Axon Body Cam	`00:25:DF`	Law enforcement body-worn cameras
Flock Safety ALPR	`70:C9:4E`, `3C:91:80`, `D8:F3:BC`	Automated license plate readers
Motorola Solutions	`4C:CC:34`	Two-way radio / body cameras
Samsung SmartTag	`64:1B:2F`	Bluetooth trackers

Tap + Add to Watchlist on any group card. Each OUI is written to lookout.csv as an OUI-only entry (visible in the editor as OUI: AA:BB:CC:*). Entries added this way are preserved across reboots and editable via Edit List.

BLE PCAP — How It Works

BLE PCAP captures BLE advertising packets and writes them to SD card in Kismet PCAPNG format — the same format used by Kismet Wireless, Wireshark, and other BLE analysis tools.

Implementation note: Packets are reconstructed from NimBLE GAP advertising reports, not from raw LL-layer radio capture. The RF channel field in each packet's pseudo-header is forced to channel 37 regardless of the actual advertising channel used. Payload and metadata come from BLE_GAP_EVENT_EXT_DISC events from the NimBLE stack, which may omit or truncate low-level LL fields present in a raw radio capture.

The ESP32-C5 uses BLE 5.0 extended advertising (CONFIG_BT_NIMBLE_EXT_ADV=y), so the scanner uses ble_gap_ext_disc() and handles BLE_GAP_EVENT_EXT_DISC events — capturing both legacy (1M PHY) and extended (Coded PHY) advertisements that legacy-only scanners would miss.

Workflow:

Open BLE PCAP from the Bluetooth tile.
A new .pcapng file is created in /sdcard/lab/ble/captures/ (e.g. ble_YYYYMMDD_HHMMSS.pcapng).
The screen shows a live packet counter. All advertising packets detected by the radio are captured, including BLE 5.0 extended advertisements.
Tap Stop to flush and close the file cleanly.

File format: PCAPNG with:

Section Header Block (SHB) — hardware, OS, and application metadata
Interface Description Block (IDB) — link type 256 (LINKTYPE_BLUETOOTH_LE_LL_WITH_PHDR)
Enhanced Packet Block (EPB) — one per advertising packet

Each EPB includes a 10-byte pseudo-header preceding the reconstructed BLE LL PDU:

Byte(s)	Field	Value
0	RF channel	37
1	Signal power (dBm)	RSSI from radio
2	Noise power (dBm)	−128 (unknown)
3–4	Access address offenses	0
5–8	Reference access address	`0x8E89BED6` (BLE advertising AA)
9	Flags	`0x02` (dewhitened PDU)

The reconstructed PDU contains the advertising PDU header (event type + address type + length), the 6-byte AdvA, and the AdvData payload. This format is directly openable in Wireshark with the BTBREDR or BTLE dissector, and in Kismet with its standard BLE plugin.

Output path: /sdcard/lab/ble/captures/ble_YYYYMMDD_HHMMSS.pcapng

Note: The ESP32-C5's BLE radio captures advertising packets on channels 37/38/39. The pseudo-header records channel 37 for all packets; the actual advertising channel is determined by the PDU type and timing.

BlueDuck — BLE HID Keyboard Injector

BlueDuck pairs with nearby Bluetooth-capable devices as a BLE HID keyboard and executes DuckyScript payloads — sending keystrokes exactly as a real Bluetooth keyboard would. It is the wireless BLE equivalent of a USB Rubber Ducky.

How it works:

Open Bluetooth → BlueDuck. Select a DuckyScript file from the list (.duck files from /sdcard/lab/ble/blueduck/scripts/) and a device persona.
BlueDuck begins advertising as the chosen persona (e.g. "Wireless Keyboard — Microsoft"). Any nearby device with Bluetooth enabled that is looking for an input device will see it.
When a target connects and completes BLE pairing, BlueDuck waits 3 seconds for the OS to complete setup, then executes the script — typing keystrokes, pressing hotkeys, and adding delays as defined.
After the script completes, BlueDuck disconnects and immediately re-advertises for the next target.

Device Personas — 9 built-in identities:

Persona	Spoofed as	BLE Appearance
Wireless Keyboard	Microsoft Surface Keyboard	HID Keyboard
AirPods Pro	Apple A2698	Headset
Fitbit Inspire 3	Fitbit FB422	Fitness Tracker
Galaxy Buds2 Pro	Samsung SM-R510	Headset
Garmin Fenix 7	Garmin 010-02540-01	Watch
Apple Watch	Apple A2976	Watch
JBL Clip 4	JBL JBLCLIP4	Speaker
Logitech MX Keys	Logitech 920-009294	HID Keyboard
Samsung 40" TV	Samsung UN40T5300	Display

Auto-rotate — cycles through all personas automatically every 5 minutes, randomizing the MAC address per persona to prevent denylisting.

DuckyScript command support:

Command	Description
`STRING`	Type literal text
`STRINGLN`	Type text + ENTER
`DELAY`	Wait N milliseconds
`DEFAULT_DELAY`	Insert delay after every subsequent command
`REPEAT`	Repeat the previous command N times
`GUI` / `CTRL` / `ALT` / `SHIFT`	Modifier keys
`ENTER`, `BACKSPACE`, `TAB`, `SPACE`, `ESCAPE`, `DELETE`	Special keys
`UP`, `DOWN`, `LEFT`, `RIGHT`, `HOME`, `END`, `PAGEUP`, `PAGEDOWN`	Navigation keys
`CAPS_LOCK`, `F1`–`F12`	Function and lock keys
`HUMAN_MODE ON/OFF`	Enable variable-speed typing for authenticity
`HUMAN_SPEED SLOW/NORMAL/FAST`	Set typing speed when human mode is active
`REM`	Comment — ignored

Script placement: Copy .duck files to /sdcard/lab/ble/blueduck/scripts/. BlueDuck scans this directory on entry and loads all scripts into PSRAM at startup — scripts are cached before BLE is initialized to avoid SD card DMA exhaustion when the BLE stack is running.

Session logging: Every connect, payload, and disconnect is appended to a JSONL session file at /sdcard/lab/ble/blueduck/blueduck_<timestamp>.jsonl — including script name, LED state (CapsLock/NumLock), GPS coordinates, pairing status, and event type.

Live stats panel on the BlueDuck screen:

Field	Description
Connects	Number of devices that have connected
Payloads	Scripts successfully executed
Disconnects	Connection terminations
Persona	Current active persona name

Script library: See resources/blueduck_scripts/ for the included script collection and full DuckyScript reference.

WhisperPair — CVE-2025-36911 Fast Pair Bypass

Legal notice — authorized use only. WhisperPair is a security research tool. Only run it against devices you own or have explicit written authorization to test. Unauthorized use may violate the Computer Fraud and Abuse Act (CFAA), the UK Computer Misuse Act, or equivalent legislation in your jurisdiction. The authors provide this tool for authorized penetration testing, academic research, and defensive security education only.

WhisperPair implements detection and exploitation of CVE-2025-36911, a vulnerability in the Google Fast Pair Key-Based Pairing (KBP) protocol disclosed in January 2026 by COSIC/KU Leuven. The flaw allows any BLE device to trigger unsolicited pairing popups on Android phones and other Fast Pair–enabled devices without any user interaction on the target.

Background — CVE-2025-36911

Google Fast Pair uses a Key-Based Pairing (KBP) handshake to accelerate the Bluetooth pairing UX. The protocol is advertised via the 0xFE2C BLE service UUID. The vulnerability: Fast Pair providers (earbuds, speakers, accessories) accept KBP packets without verifying that the device is in explicit pairing mode. An attacker can construct a valid-looking KBP packet encrypted with AES-128-ECB using the salt as the key and deliver it over BLE to any nearby Fast Pair device, triggering an Android pairing prompt on the victim's phone.

Affected devices: Any Google Fast Pair–enabled accessory (Google Pixel Buds, Samsung Galaxy Buds, Sony WF/WH series, Bose, JBL, and thousands of other accessories using the GFP SDK) running unpatched firmware.

CVSS: 6.5 Medium — does not require authentication, exploitable at BLE range (~10 m), results in unsolicited UI interaction on victim devices.

How It Works

Fast Pair providers broadcast a 0xFE2C service UUID in their BLE advertisements. A KBP packet is 16 bytes:

Byte 0:   Type = 0x00 (Key-Based Pairing Request)
Byte 1:   Flags = 0x00
Bytes 2–7: Provider MAC address (target device address, big-endian)
Bytes 8–15: Salt (8 random bytes, attacker-chosen)

The packet is encrypted with AES-128-ECB where the key is Salt || 0x00 × 8 (salt padded to 16 bytes). The provider decrypts and processes this packet — triggering the pairing flow — without checking whether it is in discoverable/pairing mode.

Access in CYM

WhisperPair is found under Bluetooth → BT Attacks → WhisperPair. The authorization disclaimer must be acknowledged before the screen opens.

Passive detection is automatic during any BLE scan. Devices advertising the 0xFE2C Fast Pair service are tagged with [FP] in the BT Scan & Select list. GATT Walker also flags these devices with a ⚠ Fast Pair (CVE-2025-36911) warning when the 0xFE2C service is discovered during a walk.

WhisperPair Screen

When opened, WhisperPair automatically runs a BLE scan to discover Fast Pair–capable devices. Any device advertising the 0xFE2C service UUID is shown in the list. Each row shows:

Device index
Device name (truncated to 12 chars)
RSSI
Partial MAC (last 3 octets)
[FP] badge

Three action buttons:

Button	Mode	Description
Probe	GATT connect	Connects to the selected device, discovers the `0xFE2C` service and the KBP characteristic (`fe2c1234-...`), confirms exploitability, disconnects cleanly
Exploit	KBP write	Connects, enables CCCD notifications, constructs and writes the crafted AES-128-ECB KBP packet, waits up to 5 s for a response notification
Run All	Sequential	Runs the selected action (Probe or Exploit) against every Fast Pair device in the list, one at a time, cycling through them automatically with a chained callback. Results for each device are logged as they complete.

Status and result display update in real time below the device list. Results are also logged to SD.

Usage

Open Bluetooth → BT Attacks → WhisperPair. Acknowledge the authorization disclaimer.
WhisperPair auto-scans for Fast Pair devices. Wait for the scan to populate the list (typically 10 seconds).
To target a single device: tap a row to select it, then tap Probe or Exploit.
To target all found devices sequentially: tap Run All — the firmware chains through each [FP] device automatically.
Results are logged to /sdcard/lab/ble/whisperpair/.

Output Log

Each probe or exploit attempt produces a JSON entry in /sdcard/lab/ble/whisperpair/:

{
  "timestamp": "20260518_193200",
  "mac": "AA:BB:CC:DD:EE:FF",
  "name": "Galaxy Buds2 Pro",
  "rssi": -54,
  "mode": "exploit",
  "kbp_chr_found": true,
  "result": "notify_received",
  "notify_hex": "1A2B3C4D5E6F7A8B9C0D1E2F3A4B5C6D",
  "gps": { "valid": true, "lat": 37.1234567, "lon": -122.4567890 }
}

result values:

Value	Meaning
`notify_received`	Provider responded with a KBP notification — device is vulnerable
`no_notify`	KBP packet written but no notification received within 5 s — may be patched
`chr_not_found`	0xFE2C service present but KBP characteristic not found
`connect_failed`	BLE connection could not be established
`probe_ok`	Probe mode: KBP characteristic confirmed present

Porting to Janos

The ble_whisperpair.c/h module is self-contained and portable. Dependencies:

NimBLE — ble_gap_connect, ble_gattc_disc_svc_by_uuid, ble_gattc_disc_chrs_by_uuid, ble_gattc_write_flat (standard NimBLE API, available in ESP-IDF and Zephyr)
ROM AES — ets_aes_enable/setkey_enc/block/disable from esp32c5/rom/aes.h — on other targets, substitute any AES-128-ECB implementation (mbedTLS mbedtls_aes_crypt_ecb or a bare-metal block cipher)
FreeRTOS — task + semaphore for async BLE serialization (replaceable with any RTOS primitives or a state machine)
SD logging — optional; the core exploit logic has no SD dependency

To port: copy ble_whisperpair.c/h, replace the AES calls with your platform's AES-128-ECB, replace the FreeRTOS semaphores with your RTOS equivalents, and wire wp_init(mutex) + wp_start(target, mode, cb) into your UI. The GATT client pattern is identical to gatt_walker.c and can share the same connection infrastructure.

3. Wardriving

GPS-enabled WiFi (and optionally BLE) mapping. Requires an ATGM336H (or compatible NMEA module) wired to IO4/IO5 — see GPS Wiring.

Wardrive
├── Start Wardrive     ← launches the live dashboard
├── Options            ← band, PCAP, and BLE settings
└── Manage Data        ← file list with upload status, delete, and upload

Starting a Wardrive

Tap Wardrive from the main menu, then Start Wardrive. The firmware switches the radio to promiscuous mode, begins D-UCB channel hopping, and writes a new WiGLE CSV 1.6 file to /sdcard/lab/wardrives/ (filename: WD_Wifi_<date>-001.csv). Files auto-rotate into sequentially numbered parts within the same journey (-001, -002, …) to stay within upload size limits.

GPS at start-up:

If a live GPS fix is already active, wardrive starts immediately.
If no live fix but a last-known position is available (from a prior session saved in NVS, or set manually), wardrive starts immediately using that position with 150 m accuracy — no blocking wait.
If neither is available (first-ever boot, no GPS module), the firmware waits in a blocking loop until a fix is acquired. Set a manual position via Settings → GPS Info → Set Position to skip this wait.

GPS loss during a session:

When signal is lost (entering a building, tunnel, underground garage), wardrive continues scanning using the last-known coordinates and reports 150 m in the AccuracyMeters CSV field.
Scanning only pauses if there is truly no position at all (no live fix, no last-known).
When signal returns, live coordinates and accuracy resume automatically.

Adaptive speed-based capture: With Speed Adaptive Mode on (default), dwell time and DFS channel weighting adjust automatically based on real GPS speed:

Profile	Trigger	Dwell	DFS
Stationary	< 5 km/h	500 ms	Full weight
Walking	5–20 km/h	300 ms	Full weight
Driving	> 20 km/h	150 ms	1 in 10 sweeps

The active profile and a live speed readout appear in the dashboard footer. The profile border is green (adaptive) or red (manual override).

The live dashboard shows:

Field	Description
Band badge	Green = 5 GHz, amber = 2.4 GHz — visible per-row in the AP table
D-UCB (green box)	Current channel being scanned — shows BLE during a BLE pass
WiFi (cyan box)	Unique WiFi networks logged this session
BLE (purple box)	BLE devices collected this session
GPS bar	Live coordinates (green) or last-known position (amber) with satellite count
GPS icon (top bar)	Green satellite = fix, grey with red slash = no fix

Stop — ends the session, closes all open files, and returns to the Wardrive menu.

Go Dark — available from the title bar power icon on every screen. The display turns off while wardriving continues in the background. The NeoPixel stays cyan while active.

Waking from Go Dark:

Boot button — press the physical BOOT button on the board.
Touch-to-wake — hold a finger on the top-right corner of the screen (where the power icon is) for about 5 seconds. Useful when the boot button is hard to reach inside a printed case.

Mark Button — GPS Waypoints

A Mark button sits in the lower-right of the wardrive dashboard (amber, GPS icon). Use it to tag any point of interest during a drive:

Gesture	Result
Double-tap (within 450 ms)	Quick waypoint — saves current GPS coordinates immediately with no note
Single tap	Opens a note dialog — enter a description, then Save to record the point with text

Waypoints are saved in GPX format to /sdcard/lab/wardrives/wdXXXXXX_marks.gpx — one file per session, named to match the session's CSV file. The file is closed cleanly when you tap Stop.

Stale position behavior: If the live GPS fix is lost at the time a mark is saved, the device falls back to the last-known position (same 150 m accuracy rule as wardrive logging). The note dialog coordinate display shows the coordinates in amber with a [stale] label so you know the position is approximate. The saved <wpt> entry includes [stale pos] appended to the <desc> field so it's visible in any GPX viewer.

GPX output:

<?xml version="1.0" encoding="UTF-8"?>
<gpx version="1.1" creator="CYM-NM28C5">
  <wpt lat="37.123456" lon="-122.456789">
    <ele>42.0</ele>
    <time>2026-05-08T12:34:56Z</time>
    <name>Mark 1</name>
  </wpt>
  <wpt lat="37.123789" lon="-122.457012">
    <ele>42.0</ele>
    <time>2026-05-08T12:36:11Z</time>
    <name>Coffee shop on corner</name>
  </wpt>
</gpx>

GPX files can be loaded directly into QGIS, Google Earth, or any mapping tool that accepts the standard GPX format.

Options Screen

Tap Options from the Wardrive menu to configure the current session parameters. All settings are NVS-persisted.

Option	Values	Default	Description
Band	Both / 2.4 GHz / 5 GHz	Both	Restricts D-UCB channel hopping to the selected band
Speed Adaptive Mode	On / Off	On	Auto-adjusts dwell and DFS weighting by GPS speed; when off, reveals Manual Mode dropdown
Manual Mode	Stationary / Walking / Driving	Driving	Fixed capture profile when adaptive mode is off; shows profile parameters in label
BLE Wardrive	On / Off	Off	Enables BLE time-sliced scanning alongside WiFi (see below)
BLE-only Wardrive	On / Off	Off	Dedicated BLE-only run — calls `esp_wifi_deinit()` to free WiFi DMA pool before NimBLE starts
GPS Baud	9600 / 115200	9600	Opt-in 115200 enables 5 Hz GPS fixes (5.2 fix/s measured); verify-and-revert safety prevents lock-out

BLE Time-Sliced Wardriving

When BLE Wardrive is enabled, the firmware periodically pauses WiFi scanning for a short BLE pass:

Every 30 seconds of WiFi scanning, the promiscuous sniffer is paused.
The radio switches to BLE mode and runs an active BLE scan (solicits SCAN_RSP — the packet where most devices advertise their name).
All discovered BLE devices (deduplicated by MAC, with name backfill on subsequent sightings) are recorded with the current GPS fix, altitude, and accuracy from the real GPS reading at detection time.
The radio switches back to WiFi, D-UCB is rebuilt, and scanning resumes.

During the BLE pass, the D-UCB box shows BLE and the purple BLE counter increments as devices are discovered.

BLE-only wardrive runs NimBLE without any active WiFi driver. In v2.12.0 this required calling esp_wifi_deinit() to release the WiFi DMA pool before NimBLE starts — without it the controller failed with 0x207 BLE_ERR_MEM_CAPACITY and collected zero devices. The BLE-only dashboard uses a dedicated B | MAC | Name | RSSI layout with a "BLE / SCAN" channel box, distinct from the WiFi dashboard. BLE device cap is 2000 (stored in PSRAM).

BLE rows in the CSV follow the same WiGLE 1.6 format as WiFi rows, with real AltitudeMeters and AccuracyMeters filled from the GPS fix at discovery time:

AA:BB:CC:DD:EE:FF,"My Speaker",[BLE],2026-05-08 12:34:56,37,2402,-72,37.123456,-122.456789,42.0,8.40,,,BLE

Mixed WiFi+BLE CSV files (from BLE time-slice mode) upload directly to WiGLE and WDG Wars — both services process both types in the same file.

D-UCB Band Filtering

The D-UCB channel scheduler respects the Band option:

Band setting	Channels hopped
Both	All 2.4 GHz channels (1–14) + 5 GHz channels (36, 40, 44, 48, 52, 56, 60, 64, 100–165)
2.4 GHz only	Channels 1–14 only
5 GHz only	5 GHz channels only

Manage Data Screen

Manage Data lists all wardrive CSV files in /sdcard/lab/wardrives/. Each row shows the filename (wrapping to two lines for long names) and upload status read from upload_log.csv:

Row color	Meaning
Green	Uploaded successfully to all selected services
Amber	Partially uploaded (e.g. WiGLE OK, WDG Wars failed)
White	Not yet uploaded

Each row has an X button to delete that file from the SD card. Tap Upload to proceed to the upload screen (which returns to Manage Data when done, so you can check updated statuses).

Journey-grouped filenames: Each wardrive session produces files named WD_Wifi_<YYYYMMDD_HHMMSS>-NNN.csv (and WD_BLE_<stamp>-NNN.csv for BLE-only runs). When a file reaches the rotation threshold, it is closed and a new part is opened with the next sequential suffix — all parts of the same journey share the same date/time stamp.

The upload log at /sdcard/lab/wardrives/upload_log.csv records one row per file per service:

WD_Wifi_20260803_141500-001.csv,WIGLE,OK
WD_Wifi_20260803_141500-001.csv,WDGWARS,OK
WD_Wifi_20260803_141500-002.csv,WIGLE,New

Wardrive File Format

WiGLE CSV 1.6 — accepted directly by WiGLE and WDG Wars without conversion.

WigleWifi-1.6,appRelease=v1.0.4,model=NM-CYD-C5,...
MAC,SSID,AuthMode,FirstSeen,Channel,Frequency,RSSI,CurrentLatitude,CurrentLongitude,AltitudeMeters,AccuracyMeters,RCOIs,MfgrId,Type
AA:BB:CC:DD:EE:FF,"MyNetwork",[WPA2_PSK],2026-08-03 14:15:23,6,2437,-65,37.123456,-122.456789,42.0,8.40,,,WIFI
11:22:33:44:55:66,"BLE Device",[BLE],2026-08-03 14:15:30,37,2402,-72,37.123456,-122.456789,42.0,8.40,,,BLE

FirstSeen is stamped from the GPS-synced clock at the moment the network is first detected. AltitudeMeters and AccuracyMeters are filled from the live GPS reading at that moment. AccuracyMeters = HDOP × 4 (e.g. HDOP 2.1 → 8.4 m); fallback coordinates produce 150.00 m. WiGLE uses this field to place networks on its map with an appropriate uncertainty radius.

Wardriving Workflow — Field Use

Quick drive:

Insert GPS module (ATGM336H) — fix typically arrives in 30–60 s with clear sky.
- If last-known position is stored (NVS), wardrive starts immediately without waiting.
Wardrive → Start Wardrive. The NeoPixel turns cyan.
Drive. The AP count increments as new networks are logged. If you enter a building and GPS signal is lost, scanning continues using the last-known position (150 m accuracy in the CSV).
Tap Stop when done. Files are closed and ready to upload.
Wardrive → Manage Data → Upload.

Indoor / no-GPS use:

Settings → GPS Info → Set Position — enter your approximate location (e.g. city centre coordinates).
Tap Save to NVS. The position is stored immediately.
Start Wardrive — the device uses the entered position for all log entries.
Networks are logged with AccuracyMeters = 150 indicating approximate coordinates.

With BLE:

Options → BLE Wardrive → On. Options → Band → Both.
Start Wardrive. Every 30 seconds the D-UCB box shows BLE for an 8-second pass; the purple BLE counter ticks up with each device found.
Both WiFi and BLE sightings appear in the same CSV.

Marking a point of interest:

Double-tap Mark to silently drop a quick waypoint.
Single-tap Mark, type a note (e.g. "camera on pole"), tap Save.
GPX file is written alongside the CSV — load both into QGIS for a full picture.

Upload after drive:

Wardrive → Manage Data → check row colors.
Tap Upload → select WiGLE / WDG Wars / Both → API keys are pre-filled if you set them by file (recommended — see below) or from a prior on-device entry → Upload All.
Per-file status updates live. Green = accepted; amber = duplicate; red = failed.
Return to Manage Data — uploaded rows turn green.

Tip — avoid typing API keys on the device: Put your keys in plain text files on the SD card before your first upload. The device loads them at boot and pre-fills the upload screen automatically — no on-screen keyboard needed.

WiGLE: create /sdcard/lab/wigle.txt — paste your WiGLE "Encoded for use" token on line 1 (get it from wigle.net → Account → API Token).

WDG Wars: create /sdcard/lab/wdgwars.txt — paste your WDG Wars API key on line 1 (from your wdgwars.pl profile page).

Copy the files to the SD card from a PC, insert the card, and reboot. The upload screen will be pre-filled on every subsequent use.

4. Settings

Settings
├── Compromised Data    (WiFi credential monitor)
├── Timing              (WiFi scan dwell + BT scan duration + GATT connect timeout — combined popup)
│   ├── WiFi Scan/Ch    (min/max dwell time per channel — 50–1000 ms sliders)
│   ├── BT Scan         (BLE initial scan duration — 10–30 s slider, default 10 s)
│   └── GATT Timeout    (BLE connect timeout — 3–30 s slider)
├── Download Mode       (reboot into bootloader)
├── Screen              (screen timeout + brightness — combined popup)
│   ├── Timeout         (inactivity timer before dimming)
│   └── Brightness      (software brightness overlay 10–100%)
├── SD Card             (provision / file tree / free space)
├── GPS Info            (live fix status)
├── Hardware Options    ← hardware addon configuration
│   ├── Power Mode      (Normal / Max TX power)
│   └── NM-RF-HAT       (Enable / Disable the RF expansion board)
└── Data Transfer       (file server sub-menu)
    ├── AP File Server  (start TheLab AP, serve /sdcard/ on 192.168.4.1)
    ├── WiFi Client     (join a saved network, serve /sdcard/ on DHCP IP)
    └── Wardrive Upload (WiGLE + WDG Wars HTTPS upload)

All settings are persisted via NVS (Non-Volatile Storage) across reboots. The settings menu fits on a single screen (8 tiles, 3-column grid, no scrolling).

Setting	Description
Timing	Combined timing popup — WiFi scan dwell time sliders, BT scan duration slider (10–30 s), and GATT connect timeout slider
Screen	Combined screen popup — inactivity timeout dropdown and brightness overlay slider
SD Card	Validate/provision (creates `/sdcard/lab/` structure, shows completion status); browse file tree; check free space
GPS Info	Live GPS fix status — latitude, longitude, altitude, satellite count, UTC time, and UART reference. When no live fix, last-known coordinates are shown in amber with `` suffix and `Accuracy: 150 m (stale)`. Set Position* button opens manual coordinate editor (see below). Refreshes every second.
Hardware Options	Sub-menu for hardware addon configuration — Power Mode (Normal / Max TX power) and NM-RF-HAT enable/disable toggle. NVS-persisted.
Data Transfer	File server sub-menu — AP mode or WiFi client mode (see below)
Vibrator Test	Test tile for the vibrator motor — drives GPIO 26 (SPEAK_IN → SC8002B amp) at 333 Hz via LEDC PWM. Popup exposes ON / OFF buttons and a Strength slider (10–100%, where 100% = 50% duty cycle, the half-wave rectified maximum). Strength persists within the session. API: `vibrator_on()`, `vibrator_off()`, `vibrator_pulse(ms)`, `vibrator_burst(count, on_ms, gap_ms)`. Requires the 1N5819 + 1N4148 diode circuit on the SPEAK header — see Vibrator Motor Circuit section.

GPS Info & Fallback Position

Accessible via Settings → GPS Info. Refreshes every second.

Live fix (GPS module connected and locked):

Field	Description
Fix	`YES` in green — active GNSS lock
UTC	Time string parsed from NMEA RMC sentence
Satellites	Count of tracked SVs from GGA
Lat / Lon / Alt	Live coordinates in white
Accuracy	Live HDOP × 4 in metres

No live fix (signal lost or module not connected):

Field	Display
Fix	`NO (last known ↓)` in amber (or `NO` in orange if no fallback at all)
Lat / Lon / Alt	Last-known coordinates in amber followed by `*`
Accuracy	`150 m (stale)` in amber

The *-suffix values are what the device is actually using as its GPS fallback for wardrive logging, GATT Walker geotags, and GPS waypoints.

Set Position button (amber):

Opens a modal overlay to manually enter fallback coordinates:

┌─ Set Fallback Position ──────────────────┐
│  Stored in NVS, used when GPS unavailable │
├───────────────────────────────────────────┤
│  Latitude (-90 to 90):   [ 37.421900    ] │
│  Longitude (-180 to 180):[-122.084058   ] │
│  Altitude (m, optional): [ 30.0         ] │
├───────────────────────────────────────────┤
│       [ ✓ Save to NVS ]  [ ✕ Cancel ]    │
└───────────────────────────────────────────┘
        [ on-screen keyboard ]

Text areas are pre-populated with the best available position: live GPS if locked, last-known from NVS if not
Accepted characters: -0123456789. only — the keyboard filters invalid input
Validation: latitude must be in [-90, 90], longitude in [-180, 180]; the null island (0, 0) is rejected. The lat field border flashes red on invalid input.
On Save: g_gps_last_known is updated immediately in RAM and written to NVS unconditionally (bypasses the 5-minute auto-save throttle — this is a deliberate user action). All subsequent wardrive scans, GATT walks, and mark waypoints use the new position.
On Cancel: no changes are written

NVS keys written by GPS (namespace settings):

Key	Type	Description
`gps_lat_i`	i32	Latitude × 10⁶ (integer micro-degrees)
`gps_lon_i`	i32	Longitude × 10⁶
`gps_alt_i`	i32	Altitude × 10 (integer deci-metres)

Integer storage avoids NVS blob overhead and gives ~0.1 m altitude resolution and ~0.11 m position resolution — well within the 150 m stale accuracy the system reports.

Write frequency and flash lifetime:

Write path	Frequency	Estimated NVS life
Auto (from GPS fix)	≤ once per 5 minutes	~5.7 years continuous use
Manual (Set Position)	On user tap only	Decades

The NVS partition is 24 KB (≈6 flash pages × 100 K P/E cycles each). At one auto-write per 5 minutes, the effective write budget of ~600 K commits lasts roughly 5–6 years of daily wardriving. SD card writes (if used for logging) are handled by the SD FTL across gigabytes of storage — the per-minute rate would be trivial.

TX Power Mode

Accessible via Settings → Power Mode. Defaults to Normal on first boot.

Mode	WiFi	BLE
Normal	Default IDF TX power, modem-sleep enabled (`WIFI_PS_MIN_MODEM`)	Default controller TX power
Max Power	TX cap set to 82 (~20.5 dBm nominal), modem-sleep disabled (`WIFI_PS_NONE`)	All BLE power types set to P9 (+9 dBm)

Switching modes takes effect immediately on the active radio and is re-applied automatically every time WiFi or BLE is started — including on attack start/stop and radio mode switches.

Note: Actual radiated power (EIRP) is still bounded by the NM-CYD-C5's PCB antenna, PHY calibration data, and the country/regulatory settings loaded at boot. Max Power increases effective range but does not bypass regulatory limits enforced by the PHY layer.

Timing Settings

Accessible via Settings → Timing. A single popup contains three sections:

WiFi Scan / Channel — min and max dwell time sliders (50–1000 ms) control how long the WiFi scanner dwells on each channel during active scans. Both values are NVS-persisted.

BT Scan Duration — a slider (10–30 s, default 10 s, NVS key bt_scan_dur) sets how long the initial BLE scan runs when opening BT Scan & Select, BT Observer, or AirTag Scan. Longer values find more devices, especially in noisy or busy RF environments; shorter values make scans feel snappier.

GATT Connect Timeout — a single slider sets the BLE connection timeout used by GATT Walker. BT Observer uses a separate fixed 5 s timeout and is not affected by this setting.

Slider position	Timeout	Best for
Far left (3 s)	3 000 ms	Fast, nearby devices that respond immediately
Default / far right (30 s)	30 000 ms	Distant, intermittent, or slow-to-respond targets

The value is saved to NVS key gatt_tmo and applied on every subsequent GATT Walker walk without needing a reboot.

Error descriptions: When a connection fails, GATT Walker now shows a human-readable reason (e.g. "No response — needs pairing or asleep" for BLE timeout code 13, "Radio busy — stop scan first" for code 15) instead of a raw numeric code.

Data Transfer

Accessible via Settings → Data Transfer.

Settings → Data Transfer
├── AP File Server      ← device creates its own WiFi network
├── WiFi Client         ← device joins your existing network
└── Wardrive Upload     ← upload CSV logs to WiGLE and/or WDG Wars

AP File Server

The device starts a WPA2-secured access point and immediately serves /sdcard/ on its default gateway address.

Detail	Value
SSID	`TheLab`
Password	`Do not touch!`
Server URL	`http://192.168.4.1`
Channel	6

Connect your phone or laptop to the TheLab network, then open http://192.168.4.1 in a browser. You get a directory listing of the SD card with full file management capability. Tap Stop on the device to shut the server down and restore normal operation.

File server capabilities:

Action	How
Browse	Click any folder to navigate in
Download	Click any file to download it
Upload	Use the upload form at the bottom of each directory listing
Create directory	Enter a name in the New folder field and click Create
Delete file	Click the ✕ button next to any file
Delete directory	Click the amber ✕ button next to any folder — requires double confirmation (recursive delete, irreversible)

All client IP addresses are logged to serial output so you can see which device is browsing or uploading.

WiFi Client Server

The device joins an existing WiFi network as a station (STA) and serves files on the IP address assigned by your router's DHCP server. The IP is displayed prominently on screen as soon as a lease is obtained.

Tap WiFi Client — the screen shows pre-filled SSID and password fields (populated from the last saved connection).
Edit SSID / password if needed — tap either field to bring up the on-screen keyboard. Tap the eye icon on the password field to reveal/mask the password.
Tap Connect — the device connects to your network. Credentials are saved to NVS so next time the fields are pre-filled.
Once connected the screen shows the assigned IP: IP: 192.168.x.x => http://192.168.x.x
Open that URL on any device on the same network to browse, upload, create folders, or delete files.
Tap Back to disconnect and stop the server.

First-connect reliability: The firmware pins the regulatory domain to International (channels 1–13, MANUAL policy) immediately before and after each connect attempt. An auto-retry fires once at 1.5–5 s if the initial association is dropped by a country-IE-induced regdomain update — this is transparent and produces no visible delay.

Note: The WiFi radio must be available (not in BLE mode) to use the file server. If BLE is active, the firmware switches radio modes automatically.

International channels: The regulatory domain is set to 01 (ITU world region) with nchan=13, covering channels 1–11 (US) and 1–13 (EU/Poland/Australia) without restriction. All access points on channels 12–13 are accessible without any configuration change.

Wardrive Upload

Uploads all wardrive CSV files from /sdcard/lab/wardrives/ to WiGLE and/or WDG Wars over HTTPS. The device connects to WiFi automatically using your saved credentials (set via WiFi Client) before uploading.

API key setup — two options (use either or both):

Option	How
SD card file	Create `/sdcard/lab/wigle.txt` and/or `/sdcard/lab/wdgwars.txt` — paste the key on the first line. Loaded at boot.
On-device entry	Tap Wardrive Upload, type the key into the text area, tap Upload All. Key is saved to NVS and persists across reboots.

WiGLE API token: Go to wigle.net → Account → API Token → copy the "Encoded for use" value (already base64 encoded — looks like dXNlcm5h...).

WDG Wars API key: Obtain from your wdgwars.pl profile page.

Upload flow:

Select service: WiGLE, WDG Wars, or Both
API key text areas are automatically pre-filled if /sdcard/lab/wigle.txt or /sdcard/lab/wdgwars.txt exist, or from a key saved on a previous visit. If neither source is present, type the key directly into the text area — it will be saved to NVS for next time.
Tap Upload All — the device connects to WiFi, walks every .csv file in /sdcard/lab/wardrives/, and uploads each one in sequence
The progress list shows per-file status: OK (green), dup (amber — already submitted), FAIL (red)
Each result is written to /sdcard/lab/wardrives/upload_log.csv; the Manage Data screen reads this file to color-code rows

Tip: Use Wardrive → Manage Data → Upload instead of Settings → Data Transfer → Wardrive Upload when you want to see file status before and after uploading. Both paths use the same upload screen and log.

6. Zigbee Scout

Zigbee Scout uses the ESP32-C5's built-in IEEE 802.15.4 radio to passively scan and wardrive Zigbee networks — no external hardware required. It operates independently of the NM-RF-HAT.

Bluetooth → Zigbee Scout
├── Start Scan     -- passive receive on all 16 channels, rotates every 800 ms
├── PAN List       -- tap any PAN to lock onto it (RSSI locator mode)
├── Stop
└── (auto-logs to /sdcard/lab/zigbee/)

What it captures:

Field	Description
PAN ID	16-bit Zigbee PAN identifier (e.g. `0x1A2B`)
Channel	IEEE 802.15.4 channel (11–26, 2405–2480 MHz)
RSSI	Signal strength in dBm
Coordinator	Extended address of the PAN coordinator (if seen in a beacon)
Node count	Number of unique device addresses seen in the PAN
Frame types	Beacon, Data, ACK, Command frame counts
NWK/APS metadata	Network/application layer frame type, destination address
GPS	Coordinates at time of reception

PAN List screen:

After a scan, tap any row in the PAN List to open the PAN detail view:

Full 64-bit extended coordinator address (if seen)
Device short address list (16-bit node IDs seen transmitting)
Frame type breakdown (Beacon / Data / ACK / Command)
RSSI locator: locks the channel and shows live RSSI for that PAN — walk toward the coordinator using the RSSI reading

RSSI Locator:

Tap Locate on any PAN entry. Zigbee Scout locks the 802.15.4 radio to that PAN's channel and displays a live RSSI reading updated every 500 ms. Use it to find the physical location of a Zigbee hub or coordinator. Vibrator strength scales with RSSI when the vibrator motor is installed.

Output files:

/sdcard/lab/zigbee/
├── zgwd_YYYYMMDD_HHMMSS.csv       -- wardrive CSV (one row per PAN sighting)
└── zgwd_YYYYMMDD_HHMMSS.pcap      -- PCAP capture (Wireshark DLT 195 = IEEE 802.15.4)

CSV columns:

Column	Description
`timestamp`	UTC from GPS-synced clock
`pan_id`	16-bit PAN ID in hex
`channel`	802.15.4 channel number (11–26)
`rssi`	dBm at time of sighting
`coordinator`	Extended coordinator address or `unknown`
`lat`, `lon`, `alt`	GPS coordinates (last-known fallback if no fix)
`gps_live`	`1` if GPS was live; `0` if last-known

The PCAP file uses DLT 195 (LINKTYPE_IEEE802_15_4_WITHFCS) and can be opened directly in Wireshark with the IEEE 802.15.4 dissector. OTA frame bytes including the 2-byte FCS are preserved.

IEEE 802.15.4 channels and Zigbee:

Channel	Frequency	Notes
11	2405 MHz	First Zigbee channel
15	2425 MHz	Common default for many Zigbee hubs
20	2450 MHz
25	2475 MHz
26	2480 MHz	Last Zigbee channel; used by some Thread networks

The Scout rotates through all 16 channels (11–26) with an 800 ms dwell per channel, completing a full sweep in ~13 seconds. Each PAN seen on any channel is de-duplicated by PAN ID in the live list.

Note: Zigbee Scout uses the ESP32-C5's hardware 802.15.4 PHY (esp_ieee802154_* API). WiFi and BLE are disabled while Zigbee Scout is running. The radio switches back automatically when you exit the screen.

8. NFC / RFID Hub

The NFC / RFID Hub tile is permanently visible on the main menu — no RF-HAT required to enter it. From the hub, choose:

Chameleon Ultra

CYM can pair with a Chameleon Ultra or Chameleon Lite over Bluetooth and use it as a full RFID/NFC read/write/emulate engine — without needing a phone or laptop.

Supported operations (v2.11.44+):

BLE scan & connect — auto-discovers Chameleon devices by NUS service UUID, shows RSSI-coded signal strength; supports both pairing-disabled and pairing-enabled units (auto-injects fixed passkey 123456 for units with BLE pairing ON)
Read LF 125 kHz — EM4100, HID Prox H10301 (FC+CN display); saves Flipper-compatible .rfid files to /sdcard/lab/rfid/lf/
Read HF 13.56 MHz — ISO 14443-A scan; MIFARE Classic, NTAG213/215/216, Ultralight detection from SAK byte; saves Flipper-compatible .nfc files to /sdcard/lab/rfid/hf/
Dump Card (full sector/page read) — appears after any card is detected on HF Read; for MIFARE Classic 1K runs a key attack (8 built-in keys + /sdcard/lab/rfid/keys/mf_keys.dic dictionary) and reads all 64 blocks; for NTAG/Ultralight reads all pages via raw ISO 14443-A READ commands; output .nfc file includes full Block N: / Page N: data in Flipper format
Slot Manager — 8-slot view showing LF/HF type per slot; activate slot, clear slot
Clone to Slot — after an LF card read, tap "Clone to Slot", pick a target slot; 4-step BLE chain writes card to Chameleon flash (EM410X and HID H10301 supported)
Load from SD — long-press any slot row to open the SD file browser; lists .rfid (LF) and .nfc (HF, NTAG/Ultralight) files; tap to load directly to that slot

Protocol reference: ChameleonUltraGUI by GameTec-live. Concept credit: @bkbroiler.

SD card layout for Chameleon:

Path	Contents
`/sdcard/lab/rfid/lf/`	LF card saves (`.rfid` — EM410X, HID Prox)
`/sdcard/lab/rfid/hf/`	HF card saves (`.nfc` — NTAG, MIFARE, Ultralight)
`/sdcard/lab/rfid/keys/mf_keys.dic`	MIFARE Classic key dictionary (one 12-hex-char key per line)

The key dictionary is seeded on first SD provision with 8 common factory/default keys. For broader coverage, download the extended dictionary from the CYM SD Asset Repository and replace the seeded file.

PN532 NFC/RFID

The PN532 tile routes to the full PN532 feature screen. Two hardware configurations are supported:

With NM-RF-HAT (DIP 3 ON): The standard path — a DIP-switch reminder popup appears before entering the feature screen.

Standalone PN532 breakout on CN1 (no RF-HAT needed): Wire a PN532 breakout board directly to the CN1 header:

PN532 pin	CN1 / ESP32-C5
SCL	GPIO 8
SDA	GPIO 9
VCC	3.3 V
GND	GND

Set the PN532 to I2C mode using its onboard DIP switch or solder bridges (varies by breakout). When RF-HAT is not enabled in Settings, tapping the PN532 tile shows wiring instructions. Enable RF-HAT in Settings → Hardware Options to see the DIP 3 reminder instead.

All PN532 feature details (Scan & Read, Clone/Write, Card Emulate, Key Test, Saved Cards, HW Test) are documented in the NM-RF-HAT section below.

7. NM-RF-HAT

The NM-RF-HAT is an optional RF expansion board that connects to the NM-CYD-C5 via its FPC2 header. It provides five RF modules gated by a 6-position DIP switch — only one module is powered at a time (hardware exclusion via P-channel MOSFETs).

Enabling the NM-RF-HAT

The RF-HAT menu tiles are hidden by default and must be enabled once after connecting the board:

Connect the NM-RF-HAT to the NM-CYD-C5 via the FPC2 ribbon connector.
Set the DIP switch for the module you want to use (only one ON at a time).
On the device, go to Settings → Hardware Options → NM-RF-HAT.
Tap Enable.
A confirmation popup appears — tap OK.
The RF-HAT tiles (CC1101, nRF24, IR, RF433, PN532 NFC) now appear on the main menu.

The setting is saved to NVS and survives reboots — you only need to enable it once. To hide the tiles again, return to Settings → Hardware Options → NM-RF-HAT and tap Disable.

Modules

DIP	Module	Frequency	GPIO9 (IO27)	GPIO8 (IO22)
1	CC1101	Sub-1 GHz (300–928 MHz)	SPI CSN	GDO0
2	nRF24L01	2.4 GHz	SPI CSN	CE
3	PN532	13.56 MHz NFC/RFID	I2C SDA	I2C SCL
4	IR Infrared	36–40 kHz carrier	TX (IR LED)	RX (demod)
5	RF433 OOK/ASK	433.92 MHz	TX	RX
6	Battery switch	—	—	—

Infrared (DIP 4)

IR capture and replay using the ESP32-C5's RMT peripheral. Files use the Flipper Zero .ir format — directly portable between this device and a Flipper Zero (mount point differs; content is identical).

NM-RF-HAT IR
├── Capture       -- listen for any IR signal (5 s timeout), keyboard-named save (remote → signal)
├── Replay        -- browse remote files -> signals -> transmit
│   ├── <Remote>.ir
│   │   ├── Signal 1
│   │   ├── Signal 2
│   │   └── ...
│   └── ...
├── LED RMT       -- 28-button NEC RGB LED strip remote (7×4 colour-coded grid; library selector)
├── Edit Files    -- rename or delete remotes and signals in saved .ir files
├── Universal     -- multi-button remote: Power Search + Power/VOL/CH/Input/Mute buttons
├── TV-B-Gone     -- transmit built-in power-off sequence for 16 common TV brands (3x repeats)
└── IR Jammer     -- continuous 38 kHz carrier via LEDC hardware PWM

SD card path: /sdcard/lab/infrared/

Capture — keyboard-named saves: When you tap Save to… after a capture, a picker shows your existing remote files plus a New remote entry (in yellow). Selecting either opens a full-screen keyboard:

New remote → type remote file name → keyboard again for signal name → saved
Existing remote → type signal name → saved immediately

The signal name is pre-filled with an auto-counter (signal_0001, signal_0002, …) that you can clear and replace. Both names are saved into the .ir file verbatim — no restrictions beyond the 31-character limit on signal names and 63 characters on remote file names.

.ir File Format

Each .ir file represents one remote (e.g. Samsung_TV.ir) and can contain any number of named signals separated by # lines:

Filetype: IR signals file
Version: 1
#
name: Power
type: raw
frequency: 38000
duty_cycle: 0.33
data: 9000 4500 560 1680 560 560 560 1680 560 560 ...
#
name: Vol_up
type: raw
frequency: 38000
duty_cycle: 0.33
data: 9000 4500 560 560 560 1680 560 560 ...

Signal values are alternating mark/space pulse durations in microseconds. frequency is the carrier in Hz (typically 38000). duty_cycle is typically 0.33 (ignored on raw TX — RMT uses fixed 33% duty).

LED RMT — RGB LED Strip Remote

A one-tap 28-button IR remote built to control NEC-protocol RGB LED strip controllers. The screen shows a 7-row × 4-column colour-coded grid where each button's background matches the colour or function it sends.

Library selector — a small toggle button in the top-right corner cycles between two button sets:

Custom — 28 verified codes captured from a physical Submersable-style LED strip remote (addr 0x00)
44-Key — 28-button subset of the standard 44-key NEC RGB LED remote (addr 0x00)

Row	Custom library buttons	NEC cmd
1	▲ Brt+ · ▼ Brt- · ⏻ OFF · ⏻ ON	`0x09` · `0x1D` · `0x1F` · `0x0D`
2	Red · Green · Blue · White	`0x19` · `0x1B` · `0x11` · `0x15`
3	OrgRed · Lime · SkyBlu · Flash	`0x17` · `0x12` · `0x16` · `0x4D`
4	Orange · Grass · Purple · Strobe	`0x40` · `0x4C` · `0x04` · `0x00`
5	Yellow · Frog · Aqua · Fade	`0x0A` · `0x1E` · `0x0E` · `0x1A`
6	YelGrn · Cyan · Magent · Smooth	`0x1C` · `0x14` · `0x0F` · `0x0C`
7	2H · 4H · 6H · TimOff	`0x02` · `0x48` · `0x54` · `0x05`

A status line at the top of the screen updates after every tap, showing the button name and the NEC command byte sent.

Protocol: NEC, address 0x00, 38 kHz carrier. The Custom library codes were captured directly from a physical remote and verified with checksum (cmd ^ ~cmd == 0xFF). If your strip controller doesn't respond to either library, use IR → Capture to record your own codes into a .ir file and play them back via Replay.

DIP switch: DIP 4 must be ON (same as all other infrared functions).

Edit Files

Browse, rename, and delete saved .ir remote files and the individual signals inside them.

Remote list — shows all .ir files on SD. Tap a remote name to open it; Rename to rename the file; 🗑 (red) to delete the entire file with a confirmation popup.
Signals view — lists every named signal in the remote. Header shows ← All (back), the remote name, a Rename button (renames the file), and a 🗑 button (deletes the file). Each signal row has its own Rename and 🗑 buttons.
Rename keyboard — teal-bordered input with a blinking cursor; matches the project-wide keyboard style. Confirms with the keyboard ✓ key or cancels with ✕.
Delete confirmation — dark modal overlay with a red card, item name, "This cannot be undone." warning, and Cancel / 🗑 Delete buttons. No destructive action fires until Delete is tapped.

Universal Remote

The Universal Remote screen provides six one-tap buttons for the most common TV functions — Power, VOL-, VOL+, CH-, CH+, Input, Mute — using signals loaded from a brand .ir file on the SD card. The active brand is saved to NVS and restored automatically every time you open the screen.

Power Search cycles through every .ir file in /sdcard/lab/infrared/, sends the Power signal from each brand, and asks "Did it work?" — tap Yes to lock in that brand, Skip to try the next, Stop to exit the search. The confirmed brand is saved immediately to NVS.

Signal name convention — Universal Remote requires these exact names:

Button	Signal name in .ir file
Power	`Power`
VOL-	`Vol_dn`
VOL+	`Vol_up`
CH-	`Ch_prev`
CH+	`Ch_next`
Input	`Input`
Mute	`Mute`

Only Power is required for the Power Search to work. The other signals are optional — a "Not found" status is shown if a button's signal is missing from the file.

The Flipper-IRDB already uses this naming convention. Files downloaded from that database work directly with Universal Remote without any editing.

TV-B-Gone

Built-in power-off sequence covering 16 common TV brands. Each code is sent 3 times with 65 ms between repeats and 250 ms between brands. DIP 4 must be ON. No SD card files required.

Getting .ir Files onto the SD Card

Compatible IR file sources:

Flipper-IRDB (most comprehensive, correct signal names): https://github.com/logickworkshop/Flipper-IRDB
Flipper Zero built-in assets: https://github.com/flipperdevices/flipperzero-firmware/tree/dev/assets/infrared/assets
IRDB community database: https://github.com/probonopd/irdb

Copy any .ir file directly into /sdcard/lab/infrared/ — no conversion needed. Files appear in the Replay remote list immediately, and the Power Search scans them automatically.

Tip: The Flipper-IRDB TV folder contains brand files with Power, Vol_up, Vol_dn, Ch_next, Ch_prev, Mute, and Input already named correctly for Universal Remote.

RF433 OOK/ASK (DIP 5)

433.92 MHz OOK/ASK capture and replay. Files use the Flipper Zero .sub (SubGHz) format — directly portable to/from Flipper Zero.

Features:

Capture: records OOK signal transitions via GPIO9 (R4A_433 RX output); saves as Flipper .sub.
Replay: plays back .sub files via the T2-433M OOK transmitter.
Jammer: T2-433M OOK transmitter toggled at 1 kHz via esp_timer (500 µs half-period), creating OOK AM sidebands around 433.92 MHz — visible modulation on a spectrum analyzer, more effective at disrupting OOK demodulators than a pure CW carrier.
LBK Test: loopback self-test verifying GPIO8 TX and GPIO9 RX path.
Fox Hunt: proximity tracker at fixed 433.92 MHz. The R4A_433 module demodulates incoming OOK signals to a digital output — edge transitions per second are counted as a signal-activity proxy. Higher activity = stronger 433 MHz signal nearby. Haptic feedback: vibrator fires at 100% strength for reliable motor spin-up; pulse rate scales from ~1 pulse/1.5 s at low activity to 5 pulses/s at peak. Note: no true RSSI — this is activity-based only.
OOK Scan: passive EV1527 protocol decoder using the R4A_433 superheterodyne receiver. Decodes 315/433 MHz OOK alarm sensors: 24-bit address, 4-bit channel/data, trigger count, last-seen time. Auto-aggregates repeat transmissions from the same sensor. Useful when CC1101 sensitivity isn't sufficient for distant sensors.

SD card path: /sdcard/lab/rf433/

Compatible .sub file sources:

Flipper Zero Sub-GHz library: https://github.com/flipperdevices/flipperzero-firmware/tree/dev/assets/subghz
UberGuidoZ collection: https://github.com/UberGuidoZ/Flipper/tree/main/Sub-GHz

PN532 NFC/RFID (DIP 3)

13.56 MHz NFC/RFID card scanning, saving, exporting, importing, and emulation via I2C (GPIO8=SCL, GPIO9=SDA). Supports ISO14443A cards: NTAG213/215/216, MIFARE Ultralight, MIFARE Classic.

SD card paths:

/sdcard/lab/rfid/hf/ -- saved card JSON files
/sdcard/lab/rfid/import/ -- drop Flipper Zero .nfc files here to import
/sdcard/lab/rfid/export/ -- Flipper Zero .nfc exports written here

Screens:

Screen	Function
Scan & Read	Hold a card near the antenna — detected in under a second. Panel border turns green, card type and UID appear. Auto-reads after 1 second of stable detection (no button tap needed). If NDEF content is present, the URL or text is decoded and shown on screen. Read button turns green when card is ready; tap it to re-read manually.
Clone / Write	Read a source card on Scan & Read, then open Clone/Write. The source card's data is shown. Hold a blank NTAG213/215/216 card on the antenna and tap Clone to Blank Card to write pages 4-44. MIFARE Classic cards are rejected with a clear error — they cannot receive NTAG data. Use a Magic/CUID blank card to clone all pages including UID.
Card Emulate	Select a saved card; PN532 enters `TgInitAsTarget` mode presenting the card's UID to any nearby reader. Responds to NTAG READ (0x30) commands using saved page data. MIFARE Classic CRYPTO1 auth is not supported in emulation.
Key Test	Present a MIFARE Classic 1K/4K card; tries 16 built-in default keys then automatically loads up to 512 additional keys from `/sdcard/lab/rfid/keys/mf_keys.dic` (same file as Chameleon Dump Card); displays unlocked block data. For authorized testing on own cards only.
Saved Cards	Scrollable list of saved JSON cards. Drop Flipper `.nfc` files in `/sdcard/lab/rfid/import/` to import directly.
HW Test	PN532 I2C probe — reads IC identifier, firmware version, support bitmask. Full I2C bus scan on failure.

Scan & Read workflow:

Open Scan & Read. Hold any NFC card near the antenna (nearly touching).
Panel border turns green within ~1 second. UID, ATQA, SAK, and card type appear.
After 1 further second of stable detection, Read All fires automatically — no tap required.
If the card contains an NDEF message (URL, text), it is decoded and shown in blue on the card panel.
Type label updates after read — e.g. if initially shown as "MIFARE Ultralight", may upgrade to "NTAG213 (45 pages)" once all pages are confirmed.
Tap Save to store as JSON, or Export .nfc for Flipper Zero format.

NTAG type identification — how it works: The PN532 on the NM-RF-HAT runs firmware v1.6 which cannot forward the NXP GET_VERSION command (0x60) to the card. NTAG213, NTAG215, NTAG216, and MIFARE Ultralight all have identical ATQA and SAK values, so they cannot be distinguished from the initial scan alone. The firmware handles this automatically:

Initial scan classifies all SAK=0x00 cards as "MIFARE Ultralight" (safe 16-page default).
After reading 16 pages, the firmware probes page 16. A genuine 16-page Ultralight returns NAK (page doesn't exist). An NTAG213/215/216 returns data.
If page 16 is readable, the card is upgraded to NTAG213 and all remaining pages (up to 45) are read automatically.
The type label and page count update on screen after the read completes.

Clone/Write compatibility: Only blank NTAG213, NTAG215, NTAG216, MIFARE Ultralight, and Magic/CUID cards can receive a clone. MIFARE Classic cards are incompatible — they use Crypto-1 sector authentication and do not accept NTAG WRITE commands. Presenting a Classic during Clone shows a red error: "Wrong card type! Need blank NTAG or Ultralight."

Serial log messages — normal vs actionable:

Log message	Meaning	Action needed
`scan: GET_VERSION failed — keeping heuristic type MIFARE Ultralight`	PN532 fw1.6 cannot forward GET_VERSION (0x60). Card identified by ATQA+SAK heuristic; NTAG auto-upgrade via page-16 probe handles the rest.	None — expected behavior
`page16 readable — upgrading Ultralight → NTAG213`	Card confirmed as NTAG213; reading all 45 pages	None — auto-upgrade working
`NDEF decoded: https://...`	URL extracted from card's NDEF message	None — URL shown on screen
`No NDEF URL/text found in 16 pages`	Card read successfully but contains no NDEF message (blank card or non-NDEF format)	None — card may be blank
`I2C write failed: ESP_ERR_INVALID_RESPONSE`	PN532 locked up after extended idle scanning. Recovery attempted automatically.	None if followed by recovery success

Flipper Zero .nfc compatibility: export and import support NTAG213, NTAG215, NTAG216 — NTAG/Ultralight type: line preserves the exact type on re-import.

Note: The PN532 on the NM-RF-HAT has shorter read range than a dedicated PN532 breakout board. Hold cards nearly touching the antenna. This is a hardware limitation of the RF-HAT PCB antenna geometry, not a firmware issue. The PN532 firmware is v1.6 and is not field-upgradeable — NXP does not distribute firmware update tools publicly.

CC1101 Sub-GHz (DIP 1)

Sub-1 GHz (300-928 MHz) OOK/ASK capture, replay, spectrum scan, and jamming. Uses a 2-page paged tile menu (prev/next navigation with page indicator).

SD card path: /sdcard/lab/radio/ -- Flipper Zero .sub format

Features:

HW Test: reads CC1101 PARTNUM (0x00) and VERSION (0x14) registers; shows MARCSTATE to confirm chip identity and SPI link. Also exposes crystal calibration (see below).
Freq Scan: canvas-based spectrum view; RSSI bar per channel across the full 300-928 MHz tunable range; carrier detect; Start/Stop control.
RAW Capture: 10-second OOK/ASK signal capture window; Save/Discard prompt after capture; saves to /sdcard/lab/radio/ as Flipper Zero .sub format.
RAW Replay: lists .sub files from SD; play at 1x/3x/5x speed.
Saved Files: list with Play and Delete per file.
Jammer: legal disclaimer screen required before activation. Band-selectable (315 / 433 Wide / 433 Narrow / 868 / 915 MHz). Uses 2-FSK at ±381 kHz deviation with 250 kbps random PRBS → ~1 MHz noise bandwidth per hop. 12-step sweep at 31 ms/step (372 ms full cycle). 433 Narrow covers 433.840–434.005 MHz (±80 kHz around 433.920). Crystal calibration offset applied to every hop.
Band Scope: 40-point spectrum + scrolling waterfall canvas; continuous sweep; live active-channel count. SDR-style frequency marker: a solid yellow vertical line appears at the center frequency on open; drag your finger across the canvas to move the line in real time (like SDRSharp or GQRX). Tap the canvas to show frequency + RSSI in the status label. Hunt button (right of Start/Stop) jumps directly to Fox Hunt at the marked frequency — tap a signal in the Band Scope, then tap Hunt to track it.
Fox Hunt: ham radio-style proximity tracker tunable across 300-928 MHz. Four preset buttons (315 / 433 / 868 / 915 MHz) plus ±0.1/±1 MHz fine-tune buttons. RSSI bar with peak hold (tap Clear Peak to reset). Adjustable squelch (±5 dBm per tap). Haptic feedback in bug-hunter style: slow pulses (1 every 2 s) just above squelch, racing pulses (10/s) at strong signals — vibration intensity also scales with RSSI. Status label: -- SILENT / > WEAK / >> MEDIUM / >>> STRONG - CLOSE!
Z-Wave Scout: passive wardrive on the Z-Wave frequency (908.42 MHz US / 868.42 MHz EU). Configures CC1101 for GFSK 9.6 kbps, sync word 0xAA01. Logs frame metadata (node IDs, command class, RSSI, GPS coordinates) to /sdcard/lab/zwave/ as a timestamped CSV. GPS-tagged entries are compatible with WiGLE for mapping Z-Wave device density.
TPMS Monitor: receives Tire Pressure Monitoring System transmissions at 315 MHz (US) or 433.92 MHz (EU). Decodes Schrader-family OOK packets — identifies each sensor by its unique 32-bit ID, displays pressure in PSI and kPa, temperature in °C, battery-low and alarm flags, and RSSI. Tracks up to 20 unique sensors in a scrollable grid. Logs all valid packets to /sdcard/lab/tpms/ as a timestamped CSV.
Weather Station: decodes Fine Offset protocol weather sensors (WH65, WH57, WS80, WH31, Froggit, Ecowitt, and compatible) at 433.92 MHz OOK. Extracts temperature (°C), humidity (%), battery status, and device ID. Displays a live scrollable list of up to 6 sensors with RSSI and last-seen age. Most Fine Offset sensors transmit every 30–60 seconds; just open the screen and wait.
Alarm Sensor: decodes EV1527 OOK alarm sensors at 315 MHz or 433.92 MHz (toggle buttons). EV1527 is the protocol used by ~90% of cheap wireless alarm products — door/window contacts, PIR motion detectors, smoke detectors, and flood sensors. Displays 24-bit unique address, 4-bit channel/button code, RSSI, trigger count, and last-seen age. Trigger a sensor (open a door, break a beam) to see its address appear instantly.

CC1101 Crystal Frequency Calibration

Consumer-grade CC1101 modules use a 26 MHz crystal with ±20-40 ppm tolerance. At common ISM frequencies this produces the following absolute error:

Frequency	±20 ppm	±40 ppm
315 MHz	±6.3 kHz	±12.6 kHz
433 MHz	±8.7 kHz	±17.3 kHz
868 MHz	±17.4 kHz	±34.7 kHz
915 MHz	±18.3 kHz	±36.6 kHz

For most applications (TPMS decoding, wardrive scanning, general capture) this is acceptable — the CC1101's wide receive filter accommodates the drift. For precise frequency measurement, jamming experiments, or calibrated fox hunting, apply the crystal offset.

Service monitor / spectrum analyzer settings for calibration:

Setting	Value
Center frequency	433.920 MHz
Span	100 kHz (±50 kHz around center — covers worst-case crystal error)
Mode	CW / Carrier detect / Spectrum
Expected signal	Continuous OOK carrier (duty = 100% while CAL TX is active)
Peak hold	ON recommended — helps capture the carrier center

The CAL TX emits a continuous RF carrier at exactly the programmed frequency (433.920 MHz ± current offset). Without any offset correction, expect to see the carrier peak 5–60 kHz away from 433.920 MHz on a typical module. Some boards with cheap crystals can be 100+ ppm off.

Calibration workflow (HW Test → Crystal Calibration section):

Fit DIP 1 (CC1101) ON and open CC1101 → HW Test.
In the Crystal Calibration panel at the bottom — current offset shown as "Offset: +138.3 ppm (+60.0 kHz @ 433 MHz)" — orange when non-zero.
Tap CAL TX 433 — button turns red ("TX ACTIVE"). The CC1101 transmits a continuous OOK carrier. Keep DIP 1 ON.
On your service monitor / SDR (set to 433.920 MHz center, 2 MHz span, peak hold ON):
- Locate the carrier peak. Read the actual frequency.
Tap Set Offset — enter the kHz deviation measured at 433.920 MHz:
- Carrier at 433.860 MHz (chip 60 kHz LOW) → enter +60.0
- Carrier at 433.980 MHz (chip 60 kHz HIGH) → enter -60.0
- Formula: entry = measured_MHz × 1000 − 433920 (kHz at 433.920 reference)
Tap Save — stored as PPM in NVS and applied to CAL TX immediately.
Verify: CAL TX carrier should now appear at exactly 433.920 MHz on the monitor.
Tap CAL TX 433 again to stop.

Quick verification: Open Fox Hunt → set to 433.920 MHz → RSSI should now peak at the calibrated frequency. Band Scope center marker confirms visual alignment.

How the offset works — PPM scaling:

The crystal error is proportional (PPM), not a fixed Hz offset. The same ppm causes different Hz errors at different bands:

Correction: hardware_freq = desired_freq × (1 + ppm / 1,000,000)

Example: 60 kHz error at 433 MHz = 138 ppm. At 915 MHz the same crystal produces 915 × 138 / 1,000,000 × 1000 = 126 kHz error. The PPM storage ensures the calibration is automatically correct at 315, 433, 868, and 915 MHz without re-calibrating per band.

Input: kHz deviation at 433.920 MHz (range ±130 kHz = ±300 ppm)
Stored: millippm (ppm × 1000) in NVS key "cc1101_ppm" (int32)
Applied: cc1101_freq_cal() wraps every cc1101_set_freq_mhz() call

Note: The FSCTRL0 hardware register also provides frequency offset correction (±202 kHz range, ~1.59 kHz/step). This firmware uses software PPM correction via cc1101_freq_cal() instead — it scales correctly to all frequencies and the offset is visible in displayed frequency values.

Z-Wave Scout

Z-Wave Scout puts the CC1101 into passive receive mode at the Z-Wave primary channel (908.42 MHz, 9.6 kbps GFSK, 0xAA01 sync word). All received frames are decoded at the link layer: source and destination node IDs, hop count, command class byte, and RSSI. Results are displayed live on screen and logged to /sdcard/lab/zwave/zwave_YYYYMMDD_HHMMSS.csv.

CSV columns:

Column	Description
`timestamp`	UTC from GPS-synced clock
`rssi`	Signal strength in dBm
`src_node`	Z-Wave source node ID (1–232)
`dst_node`	Z-Wave destination node ID or `0xFF` for broadcast
`hop_count`	Remaining hops in the routing header
`cmd_class`	First command class byte (e.g. `0x25` = Binary Switch, `0x26` = Multilevel Switch)
`lat`, `lon`	GPS coordinates at time of reception (last-known fallback if no fix)
`gps_live`	`1` if GPS was live; `0` if using last-known

Tap Stop to close the log file cleanly. Entries without GPS use the last-known NVS position with gps_live=0.

Note: Z-Wave uses 908.42 MHz in the US and 868.42 MHz in Europe/Australia. The Scout is pre-configured for the US frequency. Edit ZWAVE_FREQ_MHZ in main.c to change regions.

TPMS Monitor

The TPMS Monitor passively receives Tire Pressure Monitoring System (TPMS) sensor transmissions and decodes them in real time. Sensors are the small RF transmitters built into car wheels — they broadcast pressure, temperature, and status every 60–90 seconds at rest and more frequently while driving. Up to 20 unique sensors are tracked per session in a scrollable grid; new sensors automatically scroll into view at the bottom.

Frequency selection (on-screen):

Button	Band	Typical use
315 MHz	OOK ~9.97 kbps	US-market vehicles
433 MHz	OOK ~9.97 kbps	EU/Asia-market vehicles

Tap the active-frequency button (highlighted blue) to switch. If a scan is running, it stops automatically so the new frequency can be applied before the next Start.

Operation:

Fit DIP 1 (CC1101) ON.
Open NM-RF-HAT → CC1101 → TPMS Monitor.
Tap 315 MHz or 433 MHz to match your vehicle's market.
Tap Start — the status line shows Listening… and a packet counter updates live.
Drive or spin each tyre. Most sensors transmit within 30–60 seconds of the wheel moving. Stationary sensors transmit every 60–90 seconds.
Each unique sensor appears as its own row showing sensor ID, pressure, temperature, flags, and RSSI.
Tap Stop to end the session and close the log file cleanly.

Decoded fields per sensor:

Field	Description
Sensor ID	32-bit hardcoded sensor ID (hex) — unique per tyre/sensor unit
Pressure	In both PSI and kPa
Temperature	In °C (raw − 40 offset)
Battery low	Bit 0 of flags byte — shown as `[BATT]`
Alarm	Bit 5 of flags byte — shown as `[ALARM]`
RSSI	Signal strength at time of last reception
CRC	`[OK]` = packet CRC matched; `[?]` = CRC mismatch (shown but not logged)

Display color coding:

Amber label — pressure below 28 PSI (low tyre warning)
Green ID — last packet CRC passed
Grey ID — last packet CRC failed (data shown as reference only)

SD card logging: /sdcard/lab/tpms/tpms_YYYYMMDD_HHMMSS.csv

Column	Description
`timestamp`	UTC from GPS-synced clock
`sensor_id`	32-bit sensor ID in hex
`psi`	Pressure in PSI (1 decimal place)
`kpa`	Pressure in kPa (integer)
`temp_c`	Temperature in °C
`flags`	Raw flags byte (hex)
`rssi`	Signal strength in dBm
`crc_ok`	`1` = CRC passed, `0` = mismatch

Only CRC-valid packets are written to CSV. CRC-fail rows are shown on screen (labelled [?]) so you can see when something was received, but they are excluded from the log.

Note: The Schrader sync word (D391) covers the majority of US and EU OEM sensors. After-market sensors and some Asian-market brands may use different sync words and will not be decoded — the CRC-fail [?] row indicates a packet was received at that frequency but the format differs.

nRF24L01+ 2.4 GHz (DIP 2)

2.4 GHz channel scan, packet sniffing, and jamming. Uses a 2-page paged tile menu (same pattern as CC1101).

SD card path: /sdcard/lab/nrf24/ -- Flipper-compatible .nrf24 text format

Features:

HW Test: reads STATUS, CONFIG, RF_CH, and RF_SETUP registers over SPI; confirms chip is responding.
Ch Scan: 126-channel carrier-detect sweep (2400-2525 MHz); canvas shows spectrum bar + 8-row waterfall; Start/Stop; live active-channel count.
Packet Sniffer: promiscuous-mode RX on channel 76 (2476 MHz) with CRC disabled and a 32-byte packet size. Uses the AA:AA:AA address trick — because the nRF24 preamble byte is always 0xAA or 0x55 (matching the MSB of the first address byte), loading AA:AA:AA into the RX address makes the correlator treat any 0xAA-preamble packet as an address match, giving a wide-open receive window that catches transmissions from unknown devices without knowing their addresses. Packets are accumulated across the session and auto-saved to /sdcard/lab/nrf24/ in Flipper-compatible .nrf24 text format on Stop.
Saved Files: lists .nrf24 files with Play and Delete per entry.
Jammer: legal disclaimer required; rapid PTX channel sweep across all 126 channels.
Futaba S-FHSS: scans 25 S-FHSS channels (2404-2504 MHz, 4 MHz steps) at 1 Mbps; decodes 10-byte payload; extracts up to 8 servo channel values (11-bit, 0-2047); displays result on screen.
Fox Hunt: carrier-detect proximity tracker tunable across 2400-2525 MHz in 1 MHz steps (channels 0-125). Channel ±1/±10 step buttons plus quick presets (2400 / 2476 / 2500 MHz). Rolling 20-sample carrier-detect rate displayed as a bar + percentage. Haptic: vibrator pulses on each detection with intensity proportional to hit rate.
Stub screens (with authorization disclaimers): MouseJack, Keyboard Inject, Drone, GamePad -- Coming Soon.

nRF24 component: ESP32C5/components/nrf24/ (nrf24.c, nrf24.h, CMakeLists.txt)

nRF24 Packet Sniffer

The Packet Sniffer puts the nRF24L01+ into a wide-open promiscuous receive mode that captures transmissions from devices whose addresses are unknown.

How it works — the AA:AA:AA address trick:

The nRF24 always prepends a 1-byte preamble before the address field. The preamble is 0xAA (10101010) if the first bit of the address is 1, or 0x55 (01010101) if it is 0. By loading AA:AA:AA (all bits 1) as the receive address, the preamble flows seamlessly into the address bytes — the chip's correlator sees a continuous 10101010 10101010 10101010 10101010 pattern and treats any 0xAA-preamble packet as an address match. Combined with CRC disabled, this gives the widest possible receive window without needing to know a target's address.

Fixed parameters:

Parameter	Value	Reason
Channel	76 (2476 MHz)	Centre of 2.4 GHz ISM, low WiFi overlap
Data rate	1 Mbps	Broadest device compatibility
Packet size	32 bytes	Maximum nRF24 payload
CRC	Disabled	Allows capture of partial / foreign-format frames
Address	`AA:AA:AA`	Preamble-alignment trick (see above)

Operation:

Fit DIP 2 (nRF24L01+) ON.
Open NM-RF-HAT → nRF24 → Packet Sniffer.
Tap Start — the screen shows a live packet counter and hex dump of each received frame.
Bring target RF devices into range (other nRF24 modules, FHSS remotes, wireless keyboards/mice at rest between hops, etc.).
Tap Stop — all captured packets are saved automatically to /sdcard/lab/nrf24/ in Flipper Zero-compatible .nrf24 text format.

Note: Because CRC is disabled, some captures will be noise artifacts or corrupted frames. Use the hex dump to inspect payload patterns. Devices that use frequency hopping (e.g. Futaba S-FHSS) are better served by the dedicated Futaba S-FHSS screen which follows each hop.

UI & System Features

Feature	Description
LVGL Material Dark Theme	Modern, touch-friendly dark UI
Portrait 240×320 Layout	All screens designed and reflowed for the NM-CYD-C5's 240×320 portrait display
5-Tile Main Menu	WiFi, Bluetooth, Wardrive, Settings, Go Dark — WiFi expands to sub-menu
Unified Navigation	Single top-bar `‹ Back` on every screen steps up one menu level and fully stops the current feature (WiFi radio, BLE, RF task, RFID poll). Both Back and Home cleanly stop all running services before rebuilding the parent screen — no more orphaned background tasks or crashes when navigating away mid-capture
Screenshot Capture	Tap the title bar on any screen to save a BMP to `/sdcard/screenshots/` — works on every screen including all menus, feature pages, and live data views
WPA-SEC Upload	Upload captured handshakes to wpa-sec.stanev.org via HTTPS
NeoPixel Status LED	Mode-based color indicator via WS2812 LED (GPIO 27)

NeoPixel LED Color Reference

Color	Mode
White	Idle / system ready
Blue	WiFi scanning
Green	Passive sniffer / SnifferDog
Cyan	Wardrive
Purple	BLE scan / AirTag / BT locator
Yellow	WPA handshake capture
Amber	Deauth monitor / MITM ARP
Orange	Karma attack / captive portal
Red	Deauth / blackout / SAE overflow

Data & Storage

SD card requirement: MicroSD formatted as FAT32, 32 GB or smaller. exFAT and NTFS are not supported. SDXC cards (>32 GB) require manual FAT32 formatting before use.

All data is stored on the SD card. /sdcard/lab/ is the root for all project data:

/sdcard/
├── calibrate.txt             # Create this file to trigger touch re-calibration on next boot
└── lab/                      # Root for all project data
    ├── ouilist.bin           # OUI vendor table -- adds manufacturer names to BLE scan results
    ├── white.txt             # WiFi BSSID/SSID whitelist -- networks protected from all attacks (one per line, MAC or SSID)
    ├── eviltwin.txt          # Credentials captured by Evil Twin / Captive Portal (auto-appended)
    ├── portals.txt           # Captive portal config
    ├── wpa-sec.txt           # wpa-sec.org API key (paste key on line 1)
    ├── wigle.txt             # WiGLE API token -- base64(apiname:apitoken) from wigle.net Account page
    ├── wdgwars.txt           # WDG Wars API key from wdgwars.pl profile
    ├── alerts/
    │   ├── proximity.csv     # BLE proximity alert rules
    │   └── css_alerts.csv    # CSS alert definitions
    ├── ble/
    │   ├── captures/         # BLE PCAP files (Kismet PCAPNG, DLT 256)
    │   │   └── ble_<timestamp>.pcapng
    │   ├── honeypair/        # HoneyPair session logs
    │   │   └── honeypair_<timestamp>.jsonl
    │   ├── blueduck/         # BlueDuck session logs + DuckyScript payloads
    │   │   ├── scripts/      # Drop .duck scripts here (seeded: android_rickroll.duck)
    │   │   │   └── *.duck
    │   │   └── blueduck_<timestamp>.jsonl
    │   └── whisperpair/      # WhisperPair (CVE-2025-36911) probe/exploit logs
    │       └── wp_<timestamp>.json
    ├── bluetooth/
    │   ├── lookout.csv       # BT Lookout watchlist: MAC,name,rssi_threshold,oui_only (seeded)
    │   ├── blacklist.csv     # BT Blacklist: MAC[,oui_only] — suppressed globally (seeded)
    │   ├── spooflist.csv     # Device Spoof targets: mac,name — one entry per line (seeded)
    │   └── scans/            # BT Scan & Select saved snapshots
    │       └── btsc_00001_HHMMSS_LAT_LON_label.json   # GPS-tagged JSON; scan_id NVS-persisted
    ├── cellular/
    │   ├── tower_baseline.csv
    │   ├── tower_anomalies.csv
    │   └── raw_at.log
    ├── config/               # Optional config overrides (created by Provision)
    │   ├── detection.cfg
    │   └── provision.log
    ├── deauths/              # Deauth monitor PCAP captures
    │   └── deauth_<ts>.pcap
    ├── dronedetect/          # Drone / Remote ID detection logs
    ├── gattwalker/           # GATT Walker + BT Observer JSON fingerprints
    │   └── <name>_<MAC>_gattwalk.json
    ├── handshakes/           # Captured WPA handshakes
    │   ├── *.pcap            # Wireshark-compatible captures
    │   └── *.hccapx          # Hashcat-compatible format
    ├── htmls/                # Captive portal HTML pages
    │   ├── basic_portal.html # Seeded: dark-themed WiFi login page (posts to /login)
    │   └── *.html / *.htm    # Drop additional portal pages here -- each appears in the attack dropdown
    ├── infrared/             # NM-RF-HAT IR remotes (Flipper Zero .ir format)
    │   └── <Remote>.ir       # One file per remote — multiple named signals per file
    ├── pcaps/                # MITM/sniff PCAP captures
    │   └── mitm_<n>.pcap
    ├── nrf24/                # NM-RF-HAT nRF24L01+ captures (Flipper-compatible .nrf24 format)
    │   └── <capture>.nrf24
    ├── radio/                # NM-RF-HAT CC1101 captures (Flipper .sub format)
    │   └── <freq>MHz_<ts>.sub
    ├── rf433/                # NM-RF-HAT RF433 OOK captures (Flipper Zero .sub format)
    │   └── <Signal>.sub
    ├── espnow/               # ESP-NOW Scout device export JSON + packet logs
    │   ├── scout_<timestamp>.json    # Full device table snapshot
    │   ├── pktlog_<timestamp>.txt    # 200-frame ring buffer export (hex + ASCII)
    │   └── profiles.json    # Optional: known-device labels + LMK keys (user-created)
    ├── zigbee/               # Zigbee Scout wardrive logs (ESP32-C5 802.15.4 PHY)
    │   ├── zgwd_<timestamp>.csv   # One row per PAN sighting (PAN ID, channel, RSSI, GPS)
    │   └── zgwd_<timestamp>.pcap  # PCAP DLT 195 (IEEE 802.15.4 with FCS)
    ├── zwave/                # Z-Wave Scout captures (CC1101 908.42 MHz)
    │   └── zwave_<timestamp>.csv  # One row per received frame (node IDs, cmd class, GPS)
    ├── tpms/                 # TPMS Monitor captures (CC1101 315/433 MHz)
    │   └── tpms_<timestamp>.csv   # One row per valid Schrader packet (sensor ID, PSI, kPa, temp, flags, RSSI)
    ├── rfid/                 # NFC/RFID hub (Chameleon Ultra + PN532)
    │   ├── lf/               # LF 125 kHz card saves (Flipper .rfid — EM410X, HID Prox)
    │   │   └── <name>.rfid
    │   ├── hf/               # HF 13.56 MHz card saves (Flipper .nfc — NTAG, MIFARE, UL)
    │   │   └── <name>.nfc
    │   ├── keys/             # MIFARE key dictionaries
    │   │   └── mf_keys.dic   # Seeded: 8 common factory keys; replace with extended dict
    │   ├── import/           # Drop Flipper .nfc files here to import (PN532)
    │   │   └── *.nfc
    │   ├── export/           # Flipper .nfc exports (PN532)
    │   │   └── *.nfc
    │   └── logs/             # RFID activity logs (reserved)
    ├── screenshots/          # UI screenshots (BMP)
    │   └── screen_<n>.bmp
    └── wardrives/            # GPS + WiFi wardrive logs (WiGLE CSV 1.6 format)
        ├── wd<n>.csv         # One file per session -- uploaded via Wardrive Upload
        ├── wd<n>_marks.gpx   # GPS waypoints for that session (GPX 1.1)
        └── upload_log.csv    # Upload tracking: filename,SERVICE,STATUS per row

Screenshot Capture

Tap the title bar on any screen to capture a screenshot. The image is saved as an uncompressed 24-bit BMP to /sdcard/lab/screenshots/screen_N.bmp with an auto-incrementing index. The write runs in a background task so the UI stays responsive, and the title bar is briefly disabled while the save is in progress to prevent double-captures. Requires a mounted SD card — a warning is logged if the card is unavailable.

Screenshots are captured at full 240×320 resolution and can be opened directly in any image viewer or graphics application.

OUI Vendor Lookup

Adds manufacturer names to BLE scan results by matching each device's MAC OUI prefix against a compact vendor table loaded from SD card. Results appear as vendor names in the BT Scan & Select list (replacing [Unknown] for unidentified devices) and as an additional line in Bluetooth Lookout detection popups.

Requires a curated binary table at /sdcard/lab/ouilist.bin. Generate or refresh it whenever the IEEE OUI list changes:

Download the latest OUI CSV from IEEE Standards:
```
https://standards-oui.ieee.org/oui/oui.csv
```
Place it in the repository root (or any convenient location).

Run the converter:

python tools/oui_convert.py oui.csv ouilist.bin

Copy ouilist.bin onto the SD card under /lab/:
```
/sdcard/lab/ouilist.bin
```

The firmware loads the binary into PSRAM on first entry to any BT feature and searches it with binary search — no large stack allocations. If the file is missing, vendor lookup is skipped transparently and scan results show [Unknown] as before.

MIFARE Key Dictionary

The Dump Card feature on the Chameleon Ultra HF Read screen can crack MIFARE Classic sector keys using a dictionary attack. CYM tries 8 built-in factory/default keys automatically, then loads extras from:

/sdcard/lab/rfid/keys/mf_keys.dic

Format: one key per line, 12 hex characters (6 bytes), comments start with #:

# My custom site keys
FFFFFFFFFFFF
A0A1A2A3A4A5
D3F7D3F7D3F7
000000000000

SD Provision seeds this file with the 8 most common defaults. For broader coverage (common vendor keys, leaked key sets, etc.), download the extended dictionary from the CYM SD Asset Repository and replace the file. The dictionary can have up to 512 entries; larger files are capped at that limit.

CYM SD Asset Repository

Pre-built SD card assets are hosted at github.com/JimGat/CYM-SD-Assets. Download these files and place them in /sdcard/lab/ before first use for the best out-of-box experience:

File	Destination	Purpose
`ouilist.bin`	`/sdcard/lab/ouilist.bin`	OUI vendor table — adds manufacturer names to BLE scan results (binary-search lookup)
`mf_keys.dic`	`/sdcard/lab/rfid/keys/mf_keys.dic`	Extended MIFARE Classic key dictionary for Dump Card sector attacks

Additional assets in the repository:

mf_keys.dic — extended MIFARE key list (common vendor keys, leaked key sets, broader coverage than the 8 built-in defaults)
ouilist.bin — pre-built OUI binary (regenerate anytime with python tools/oui_convert.py oui.csv ouilist.bin from a fresh IEEE OUI CSV)

Both files are optional — CYM runs without them, but OUI lookup will show [Unknown] and MIFARE dumps will only try the 8 built-in default keys.

The SD Card → File Tree utility (Settings menu) lets you browse the SD card's directory tree directly on the device — useful for confirming handshakes and wardrive logs were saved without needing to remove the card.

SD Card Provision (Settings → SD Card → Provision) creates the full /sdcard/lab/ folder structure in one tap. When complete, the screen shows a "Done — N created, M OK" summary in a status bar above the Back button.

Touch Calibration

The XPT2046 resistive touch panel requires one-time calibration to map raw ADC values to screen coordinates. Calibration data is saved in NVS and survives reboots.

First Boot

Calibration runs automatically the first time the firmware boots (when no NVS calibration is found). The sequence appears after the splash screen, with the lab background image displayed at high brightness and yellow L-shaped corner brackets marking each tap target:

"Tap the corner: Top-Left (1/4)" — tap firmly in the top-left corner of the screen where the yellow L-bracket is shown.
"Tap the corner: Top-Right (2/4)" — tap the top-right corner.
"Tap the corner: Bottom-Left (3/4)" — tap the bottom-left corner.
"Tap the corner: Bottom-Right (4/4)" — tap the bottom-right corner.
Confirm step — a small green OK button appears at screen center with a 5-second countdown. The new calibration is applied immediately. Tap the OK button using the new calibration:
- Tap lands on OK → calibration is saved to NVS.
- Countdown expires or tap misses → old calibration is restored and the 4-point sequence restarts from the beginning. NVS is never written until OK is successfully hit.

The 4-point corner method records raw ADC values at the actual screen edges (not inset positions), so the full pixel range maps accurately with no extrapolation error. Column and row averages are used directly as x_min/x_max/y_min/y_max.

Re-Calibrating

Three ways to trigger re-calibration after first boot:

Settings → Screen → Recalibrate Touch — invalidates the NVS magic value and restarts the device; calibration runs on the next boot.
SD card trigger file — create /sdcard/calibrate.txt (content does not matter). On the next boot the firmware detects it, deletes it, and runs calibration before showing the home screen.
NVS magic reset — setting the magic key in namespace touch_cal to any value other than 0xCA15 will trigger recalibration on next boot.

What Is Stored (NVS namespace `touch_cal`)

Key	Type	Description
`x_min` / `x_max`	i32	Raw ADC X range — values at actual screen corners
`y_min` / `y_max`	i32	Raw ADC Y range — values at actual screen corners
`null_x` / `null_y`	i32	Reserved (set to 0; null-zone filtering disabled)
`invert_x` / `invert_y`	u8	Axis inversion flags (NM-CYD-C5: both typically `1`)
`swap_xy`	u8	Axis swap (typically `0` for portrait)
`magic`	u16	`0xCA15` — marks calibration as valid

Default Fallback

If NVS has no valid calibration (i.e., magic ≠ 0xCA15), the firmware applies hardware-observed defaults for the NM-CYD-C5: both axes inverted (invert_x = true, invert_y = true). These defaults allow basic interaction but will be inaccurate near the screen edges. Run calibration for accurate full-screen touch.

Building & Flashing

Prerequisites

ESP-IDF release/v6.0 branch tip (NOT the v6.0 tag — it's missing critical post-release fixes)
NM-CYD-C5 board (ESP32-C5-WROOM-1-N168R)

Build

cd ESP32C5
idf.py set-target esp32c5
idf.py build

After each build the compiled binaries are automatically copied to ESP32C5/binaries-esp32c5/.

Flash — Web Flasher (Easiest — No Install Required)

https://jimgat.github.io/CYM/

A custom-built browser flasher using Chrome or Edge WebSerial. No drivers, no terminal, no file selection — everything is fetched automatically. Click the LAB5 logo on the page to visit the store.

Channels

Button	Source	When to use
Stable	`main` branch — GitHub Pages CDN	Production releases
Dev	`Jimgat_Dev` branch — raw GitHub	Latest dev builds

Connection flow

Put the board in ROM mode: hold BOOT → plug USB-C → release BOOT
Click Connect — the flasher will:
- Detect the ESP32 Native USB bridge
- Sync with the ROM bootloader
- Identify the chip (ESP32-C5 revision 1.0)
- Upload the tasmota flash stub (required for the OPI PSRAM used on this board — standard esptool-js cannot communicate with flash while PSRAM is initialized)
The Flash button glows bright red when the board is connected and armed

Flash buttons

Button	What it flashes	Time
Flash All	bootloader (0x2000) + partition table (0x8000) + app (0x10000)	~17 s
Quick Flash	app binary only (0x10000)	~16 s

Quick Flash is for routine dev-cycle updates when the bootloader and partition table have not changed. It connects, uploads the stub, and writes only CYM-NM28C5.bin. Use Flash All after any partition layout change or for a fresh board.

The Erase checkbox performs a full flash erase before writing — use only when recovering from bad partitions, bootloops, or stale NVS config. Normal updates do not need it.

After flashing the board auto-reboots. The flash progress bar sweeps 0-100% during the write.

Serial monitor

The flasher includes a built-in UART monitor. After the board reboots, click Monitor and select the same serial port — no separate terminal app needed. Useful for reading the boot log, GPS output, or any serial debug immediately after flashing.

Baud rate

Default is 115200 baud which is reliable for all conditions. Higher rates (460800, 921600) are available but may fail on some USB hubs or cables.

Flash — Command Line

idf.py -p /dev/ttyACM0 flash monitor

Or with esptool directly:

esptool.py --chip esp32c5 --port /dev/ttyACM0 --baud 460800 \
  --before default-reset --after hard-reset \
  write_flash --flash-mode dio --flash-freq 80m --flash-size 16MB \
  0x2000 bootloader.bin 0x8000 partition-table.bin 0x10000 CYM-NM28C5.bin

Photos

Device — Front View

Device — Back / Wiring

Home-made waveshare build

Project Structure

CYM-NM28C5/
├── ESP32C5/
│   ├── main/
│   │   ├── main.c                # Core application — all UI screens, boot sequence,
│   │   │                         #   WiFi/BLE logic, touch calibration, GPS, wardriving
│   │   ├── attack_handshake.c/h  # WPA handshake capture (PCAP & HCCAPX)
│   │   ├── ble_blueduck.c/h      # BlueDuck BLE HID keyboard — GATT service registration,
│   │   │                         #   HID report handle lifecycle, persona management
│   │   ├── ble_whisperpair.c/h   # WhisperPair CVE-2025-36911 — portable NimBLE GATT client,
│   │   │                         #   AES-128-ECB KBP packet construction, FreeRTOS task lifecycle
│   │   ├── bt_lookout.c/h        # Bluetooth Lookout — CSV watchlist, LED alerts, OUI matching
│   │   ├── oui_lookup.c/h        # OUI vendor lookup — PSRAM binary search over ouilist.bin
│   │   ├── gatt_walker.c/h       # GATT Walker — NimBLE GATT client, JSON output, FNV-32 fingerprint
│   │   ├── xpt2046.c/h           # XPT2046 SPI touch driver (polling, null-zone, calibration)
│   │   ├── lvgl_memory.c/h       # PSRAM allocator for LVGL
│   │   └── dexter_img.c/h        # Dexter mascot image data (splash screen, RGB565)
│   ├── components/
│   │   ├── wifi_cli/             # CLI, WiFi init, LED control; wifi_common.c/h (shared constants)
│   │   ├── wifi_scanner/         # Active WiFi scan engine, target BSSID tracking
│   │   ├── wifi_sniffer/         # Promiscuous sniffer, SnifferDog, probe request logging
│   │   ├── wifi_attacks/         # Deauth, Evil Twin, Captive Portal, Karma, SAE Overflow
│   │   ├── wifi_wardrive/        # GPS + WiFi wardriving, SD card CSV logging
│   │   ├── sniffer/              # Raw 802.11 frame capture
│   │   ├── frame_analyzer/       # EAPOL / beacon / probe frame parsing
│   │   ├── pcap_serializer/      # PCAP file writer (Wireshark-compatible)
│   │   ├── hccapx_serializer/    # HCCAPX file writer (hashcat)
│   │   ├── led_strip/            # Local WS2812 RMT driver (replaces legacy managed component)
│   │   ├── rfid/                 # NFC/RFID card management (PN532 I2C driver, Flipper .nfc file I/O, JSON card storage)
│   │   ├── nrf24/                # nRF24L01+ 2.4 GHz driver (SPI, channel scan, packet sniffer, S-FHSS decoder, Flipper .nrf24 I/O)
│   │   └── espressif__esp_lcd_ili9341/  # ST7789 LCD panel driver (Espressif component, local copy)
│   ├── binaries-esp32c5/         # Pre-built flashable binaries (bootloader, partition-table, app)
│   ├── docs/
│   │   ├── index.html            # Web flasher UI
│   │   └── manifest.json         # OTA / web flash manifest
│   ├── partitions.csv            # nvs(24K) phy_init(4K) factory(7MB) storage(960K)
│   ├── sdkconfig.defaults        # Default Kconfig values (PSRAM, dual-band WiFi, LVGL)
│   ├── post_build.cmake          # Copies build artifacts → binaries-esp32c5/ after each build
│   ├── sdkconfig
│   └── CMakeLists.txt
├── docs/
│   └── screenshots/              # Screenshot assets used in this README
├── NM-CYD-C5-pinmap.md          # Full GPIO pin map with migration notes
├── CLAUDE.md                     # Claude Code project instructions
└── README.md

BMorcelli Launcher Compatibility

This firmware is compatible with bmorcelli/Launcher and is available in the Beta Release channel for the NM-CYD-C5.

Flashing Launcher via Web Flasher

Open the Launcher Web Flasher in Chrome or Edge
Select Beta Release as the release channel
Select CYD as the device category
Select NM-CYD-C5 from the device list
Connect your NM-CYD-C5 via USB-C and follow the on-screen instructions

Once Launcher is running, place CYM-NM28C5.bin on the SD card and select it from the Launcher file manager to install this firmware.

Installing via Launcher OTA Favorites

You can also install directly through the Launcher OTA screen without copying the binary manually. Add the following entry to config.conf on your SD card (create the file if it does not exist):

{
  "favorite": [
    {
      "name": "Cheap Yellow Monster",
      "fid": "",
      "link": "https://github.com/JimGat/CYM/releases/latest/download/CYM-NM28C5.bin"
    }
  ]
}

This entry will appear in the Launcher OTA favorites list and install the latest release directly to the device.

On Signal Jamming

Signal jamming features are included in the NM-RF-HAT menu (CC1101 Sub-GHz jammer, nRF24L01+ 2.4 GHz channel sweep jammer, IR jammer, RF433 jammer) for use in authorized test environments only -- for example, a Faraday cage or under a written test authorization from the operator of the frequency band. Every jammer entry point is gated behind an explicit legal disclaimer screen that must be acknowledged before activation.

Jamming operates at the physical RF layer and is inherently indiscriminate. Unlike protocol-layer attacks (deauth, BLE spam), it cannot be targeted, cannot be recalled once transmitting, and cannot distinguish a test device from emergency communications equipment. Use only in an environment where you have complete control over the RF spectrum -- a shielded room, an RF test chamber, or a hardware-isolated test bench. Never operate a jammer in a residential building, vehicle, public space, or any environment with uncontrolled RF exposure.

The FCC is explicit: "The Communications Act of 1934, as amended, prohibits the operation, manufacture, importation, marketing, and sale of equipment designed to jam or otherwise interfere with authorized radio communications... These jamming devices pose significant risks to public safety and potentially compromise other radio communications services."

The consequences are equally clear. Per the FCC Jammer Enforcement page: "Signal jamming devices can prevent you and others from making 9-1-1 and other emergency calls and pose serious risks to public safety communications... The use or marketing of a jammer in the United States may subject you to substantial monetary penalties, seizure of the unlawful equipment, and criminal sanctions including imprisonment."

This is not a uniquely American position. Every jurisdiction with a radio communications law -- which is effectively every country on Earth -- treats jamming as a serious criminal offense precisely because the harm is real and uncontrollable. The disclaimer screens exist to make the legal exposure clear; they do not make operation legal outside an authorized environment.

Community

CYM is not an official LAB5 project, but it is unofficially supported by the LAB5 community. The NM-CYD-C5 hardware community lives on the LAB5 Discord, and CYM has a dedicated thread there for setup help, field tips, and development discussion.

→ Join the LAB5 Discord — direct invite

→ lab5.eu.com — website and forums

Support This Project

If you find Cheap Yellow Monster useful and would like to support its continued development, consider buying me a coffee! Your support helps fund hardware, research, and development time.

Disclaimer

This project is intended for educational and authorized security research purposes only. Unauthorized access to computer networks is illegal. Always obtain proper authorization before testing on any network you do not own. The author assumes no liability for misuse of this software.

Don't Be A Skid!

🙏 Thank You

This project wouldn't be where it is without the brilliant minds and generous time of the following people. They've tested the firmware under brutal conditions, caught bugs before they reached users, reviewed code with a critical eye, and submitted fixes that made everything better.

Heartfelt thanks to:

@birolt29 — An extraordinary contributor who has gone far above and beyond at every stage of this project. @birolt29 performed deep ESP32-C5 DMA and render pipeline analysis on real hardware, submitted multiple major patch sets, and caught critical bugs before they ever reached users. Contributions include: the v2.10.15 hardware optimization patch (upload stability, mbedTLS PSRAM routing, BLE Spam memory hardening); the v2.11.x render performance series (LCD SPI 40→80 MHz, internal DMA draw buffers, -O2 optimization, LVGL memcpy, 15 ms refresh period, PSRAM 80 MHz — bringing full-frame render from 148 ms to ~77 ms); the SD remount mutex fix that eliminated a hard reset race; moving 17.4 KB of IR/RF433 name tables to PSRAM BSS; the GATT Walker double-init reset fix; diagnosing and fixing the wardrive GPS crash (GitHub issue #12 — stack-allocated lv_msgbox button map dangling after function return); and for v2.12.0, an entire wardrive overhaul: fixing a silent SD mutex self-deadlock that froze the device mid-session; root-causing and fixing BLE-only wardrive which had been collecting zero devices for months (esp_wifi_deinit() needed before NimBLE); +52% DMA headroom by moving five large arrays to PSRAM BSS (internal BSS 129 KB → 113 KB, wardrive DMA floor 20,807 → 31,615 bytes); GPS boot-time baud auto-detect and optional 115200 / 5 Hz with multi-vendor commands (CASIC, MTK, u-blox); adaptive speed-based capture profiles with D-UCB bandit and DFS tier-weighting; GPS status icon in the top bar; FirstSeen fix (was hardcoded 2025-09-26); CSV fsync power-cut safety; journey-grouped CSV rotation; BLE active scan with SCAN_RSP name backfill; BLE-mode dashboard; AltitudeMeters and AccuracyMeters filled from real GPS; and serial-validated testing of every change on real hardware. The firmware is faster, more stable, and more reliable because of @birolt29. 🙏
Anubis — For creating the first community video showcase of CYM in the wild. Taking the time to film, edit, and publish a video of this project means the world — it helps new users discover what CYM can do and gives the project a presence beyond GitHub. Thank you! 🎬
Kal (Valleytech Custom Solutions) — For a thorough and fair video walkthrough of CYM v2.12.0 on the Valleytech Custom Solutions channel. The review covered the web flasher, Chameleon Ultra integration, Zigbee Scout, Go Dark mode, WiFi/BLE feature depth, and the broader Lab5/NerdMiner ecosystem. The feedback from the video and comments directly drove first-run UX improvements in v2.12.2. Thank you! 🎬
ᛕ ᛊ ߇ ᛙ ᚢ (Kevin) — For deep technical testing and helping diagnose the toughest issues
sithwrld999 — For thorough testing and finding edge cases we missed
bkbroiler — For hands-on testing, constructive feedback, and the original concept behind the Chameleon Ultra BLE integration — the idea of using CYM as a wireless RFID controller came from them
HeavyButter — For testing and just being Paranoid Butter
eCowboy — For Hardware testing and design suggestons
OrdoOuroborus — For testing, review, and contributions for feature ideas

Your help made this toolkit more robust, more reliable, and better for everyone. 💙

Made with ☕ and ESP-IDF

KAL, I love your face!

Name		Name	Last commit message	Last commit date
.claude/rules		.claude/rules
.github/workflows		.github/workflows
ESP32		ESP32
ESP32C5		ESP32C5
ESP32S3		ESP32S3
docs		docs
resources		resources
scripts		scripts
tools		tools
.DS_Store		.DS_Store
.gitignore		.gitignore
GPIO Map Between NM-RF-HAT and NM-CYD-C5.md		GPIO Map Between NM-RF-HAT and NM-CYD-C5.md
Makefile		Makefile
NM-CYD-C5-pinmap.md		NM-CYD-C5-pinmap.md
README.md		README.md
SMOKE_TEST.md		SMOKE_TEST.md

Latest commit

History

Folders and files

Repository files navigation

Cheap Yellow Monster

🎬 Featured Videos

Cheap Yellow Monster — CYM-NM28C5

Supported Hardware

Table of Contents

Features Overview

Menu Map

Screenshots

Hardware

Pinout

Wiring Diagram

Complete GPIO Table

SPI Bus Architecture

GPS Wiring — ATGM336H

Vibrator Motor Circuit

3D Printable Cases

Case 1 — NM-RF-HAT + CYD2USB + ATGM336H + 18650 Battery

Case 2 — Magnetic Enclosure (6×2mm Magnets)

Case 3 — The Cool One

Software Features — Detailed

1. WiFi

WiFi Scan & Attack

Evil Portal Resources

Global WiFi Attacks

WiFi Observer & Karma

Deauth Monitor

Deauth Client

Chanalizer

WiFi Band Scope

ESP-NOW Scout

2. Bluetooth

Drone Detector — How It Works

Drone Spoof — How It Works

BT Scan & Select — How It Works

List Wizard — How It Works

Multi-Session Counter-Surveillance Workflow

Tracker Scanner (AirTag / SmartTag / Tile) — How It Works

GATT Walker — How It Works

BT Observer — How It Works

GATT Walker — Extended Probe (CCCD Subscription)

GATT Interactive — Live Read / Write / Subscribe

GATT HID Decoder

Saved GATT Clones

BLE Notify Logger (BLE MITM)

Bluetooth Lookout — How It Works

OUI Groups

BLE PCAP — How It Works

BlueDuck — BLE HID Keyboard Injector

WhisperPair — CVE-2025-36911 Fast Pair Bypass

Background — CVE-2025-36911

How It Works

Access in CYM

WhisperPair Screen

Usage

Output Log

Porting to Janos

3. Wardriving

Starting a Wardrive

Mark Button — GPS Waypoints

Options Screen

BLE Time-Sliced Wardriving

D-UCB Band Filtering

Manage Data Screen

Wardrive File Format

Wardriving Workflow — Field Use

4. Settings

GPS Info & Fallback Position

TX Power Mode

Timing Settings

Data Transfer

6. Zigbee Scout

8. NFC / RFID Hub

Chameleon Ultra

PN532 NFC/RFID

7. NM-RF-HAT

Enabling the NM-RF-HAT

What Is Stored (NVS namespace `touch_cal`)
